Dualcom Pro Range; Specifications - CSL DualCom Pro Series Quick Manual & Instruction Manual

Figure 11 -

DUALCOM PRO RANGE

DIGIAIR PRO
PATH
Radio 4G
LAN
Wi-Fi (coming soon)
GRADESHIFT PRO
PATH
LAN/Radio 4G
Radio 4G/ Radio 4G

SPECIFICATIONS

Dimensions
Weight
Temperature
Humidity
Mounting
Warranty
Power Requirement
Current Consumption
Radio Path
Aerial
Operation Method
CIE Interconnections
RCT Protocols
Input Terminals
Low Battery
User Serviceable Parts
Environmental
Applicable Standards
AVAILABLE GRADES
SP2
SP2
SP2
AVAILABLE GRADES
DP2
DP2+
DP3
DP2
DP2+
DP3
DP4
75 mm (h) x 119mm (w) x 15mm (d) or 75mm (h) x 119mm (w) x
32mm (d) with secondary radio module
113g excluding aerial
-10 C° to + 55 C°
Humidity – 90% non-condensing
Via fixing points under main cover
5 years
10 - 36 Volts DC
From 35mA to 175mA dependant on variant
2G, 3G, 4G
50 ohm (nominal) on MMCX socket
Store and forward
Input triggering (standardised parallel), RS232, RS485, TTL
SIA
Max +30v, Min 0 volts DC (reference supply 0v supply) 100k
7.6V DC +/- 0.5 VDC
There are no serviceable parts within the DualCom Pro Range
Class II
Suitable for use in alarm systems complying to:
EN50131-1:2006+A2:2017
EN50131-10:2014 Type Y
EN50136-1:2012+A1:2018 SP1,SP2,SP3,SP4,DP1,DP2,DP3,DP4
EN50130-5
Emissions Standard – 2014/53/EU (RED)
PD6662:2017 / PD6669:2017
ATS Classification: EN50136 ATS5/DP4 Max
ATS 5 parameters: D3/M3/T4/S2/I3/A3
WHAT'S IN THE BOX
DigiAir Pro, serial cable & small
aerial
DigiAir Pro, serial cable, Ethernet
Cable & LAN connector adaptor
DigiAir Pro, serial cable, Ethernet
Cable, Wi-Fi board & Wi-Fi
module enclosure
WHAT'S IN THE BOX
GradeShift Pro, serial cable, single
T-bar aerial, Ethernet Cable, & LAN
connector adaptor
GradeShift Pro, secondary radio
module, serial cable, Dual T-bar
aerial
13
PART NUMBER
CS.51.R2
CS.51.L2
CS.51.W2
PART NUMBER
CS.53.LR2
CS.53.LR2P
CS.53.LR3
CS.53.RR2
CS.53.RR2P
CS.53.RR3
CS.53.RR4
