Once the lock is re-aquired, the internal GPS unit will remember the local conditions and the next time the lock process will take
less than 5 minutes (depending on antenna placement and how far the Fox has been moved since being turned off).
Whenever possible, place the GPS antenna on a metal surface (such as the roof of an auto). For best results, the antenna should
be able to "see" a large portion of the sky (not blocked by buildings or trees).
CAUTION: DO NOT turn the GPS power on or off while the
turning on the main power switch.
FOX Supplemental Material
FOX
data file structures
NOTE:byte - 8 bit unsigned value
word - 16 bit unsigned value
Common to RF DUMP (serial) and ATA files
Fox type and measurement code:
Each file will contain an 8 bit code that identifies the type of measurement contained in the file and the type of
make the measurement. Bits 3-0 contain the measurement code as follows:
MEASUREMENT CODES
Value
(bit 3-0)
1 CO-CHAN
2 ADJ-CHAN
3 1 chan
4 Survey 20 chan
5 Var Sweep
6 1 Mhz sweep
7 POCSAG DATA
8 fast fade
Bits 7-4 (high nibble) contain the Fox Type code. Use this code to determine the channel number to frequency conversion.
Code (hex) FOX
0x10 851-869
0x20 900-930
0x30 935-941
0x40 928-941
0x50 806-824
0x60 869-893
0x70 824-848
0x90 Reserved
0xa0 928-941/Pocsag 928
0xb0 145-160
0xc0 220-222
0xd0 450-465
0xe0 1850-1890
0xf0 1930-1970
Measurement
type Base Freq (MHz)
851
900
935
928
806
869
824
145
220
450
1850
1930
Page 27
FOX main power switch is on. When using the GPS, turn on BEFORE
Step (KHz)
12.5
12.5
25
12.5
12.5
12.5
30
30
10
5
12.5
50
50
FOX used to
