Figure 3-4. VBUS output voltage vs current
3.4 Disconnecting the On-Board Debugger
The block diagram below shows all connections between the debugger and the PIC18F47Q10
microcontroller. The rounded boxes represent connections to the board edge on PIC18F47Q10 Curiosity
Nano. The signal names are shown in
board.
Figure 3-5. On-board Debugger Connections to the PIC18F47Q10
By cutting the GPIO straps with a sharp tool, as shown in
debugger and the PIC18F47Q10 are completely disconnected. To completely disconnect the target
regulator, cut the VTG strap shown in
©
2019 Microchip Technology Inc.
Figure 3-1
VBUS
VBUS
USB
LDO
VCC_P3V3
PA04/PA06
PA07
PA08
PA16
PA00
PA01
DIR x 5
Figure
PIC18F47Q10 Curiosity Nano
and printed in silkscreen on the bottom side of the
VOFF
VCC_LEVEL
LDO
DBG0
DBG1
DBG2
DBG3
Level-Shift
CDC TX
CDC RX
CDC RX
CDCTX
Figure 3-6, all I/Os connected between the
3-6.
User Guide
Curiosity Nano
VTG
VCC_TARGET
CUT STRAPS
TARGET
DBG0
DBG1
DBG2
DBG3
DS40002103A-page 11
