PEERLESS ACC517 Installation And Assembly

Dvd/vcr mount connector

Installation and Assembly:

DVD/VCR Mount Connector

Model: MIS517

ACC517

NOTE: Read entire instruction sheet before you start installation and assembly.

• Do not begin to install your Peerless product until you have read and understood the instructions and warnings

contained in this Installation Sheet. If you have any questions regarding any of the instructions or warnings, please

call Peerless customer care at 1-800-729-0307.

• This product should only be installed by a qualified professional.

• Make sure that the wall will safely support the combined load of the equipment and all attached hardware and compo-

nents.

• Always use an assistant or mechanical lifting equipment to safely lift and position equipment.

• Tighten screws firmly, but do not overtighten. Overtightening can damage the items, greatly reducing their holding

power.

3215 W. North Ave. • Melrose Park, IL 60160 • (800) 729-0307 or (708) 865-8870 • Fax: (708) 865-2941 • www.peerlessmounts.com

WARNING

ISSUED: 10-30-15 SHEET #: 126-9087-1

Table of Contents

Need help?

Do you have a question about the ACC517 and is the answer not in the manual?

Page 1 NOTE: Read entire instruction sheet before you start installation and assembly. WARNING • Do not begin to install your Peerless product until you have read and understood the instructions and warnings contained in this Installation Sheet. If you have any questions regarding any of the instructions or warnings, please call Peerless customer care at 1-800-729-0307.
Page 2 Before you begin, make sure all parts shown are included with your product. Parts List y. Part # c i t M5 x 8 mm phillips screw 570-0005 M4 x 8 mm phillips screw 520-1237 M4 x 12 mm phillips screw 504-9013 #8 SAE flat washer 540-1001...
Page 3 Attach two vertical brackets (A) to hanging bracket (C) Attach bracket mount tray (B) to vertical brackets (A) with four M4 x 8 mm phillips screws (E). with four M4 x 8 mm phillips screws (E). Attach VCR mount (not included) to bracket mount tray (B) with four M5 x 8 mm phillips screws (D). Use cable ties (H) for cord management once screen is attached to mount.
