Installation and Assembly:
Floor Stand Carriage for Additional Screens
Model: ACC 604
3215 W. North Ave. • Melrose Park, IL 60160 • (800) 729-0307 or (708) 865-8870 • Fax: (708) 865-2941 • www.peerlessmounts.com
ACC 604
FPZ-600
Max Load Capacity For Floor Stand With ACC 604:
Four screens at 200 lb (90.7 kg) each
ISSUED: 2006-02-14 SHEET #: 202-9111-3 (2020-06-04)
Advertisement
Related Manuals for PEERLESS ACC 604
Summary of Contents for PEERLESS ACC 604
- Page 1 ACC 604 FPZ-600 Max Load Capacity For Floor Stand With ACC 604: Four screens at 200 lb (90.7 kg) each 3215 W. North Ave. • Melrose Park, IL 60160 • (800) 729-0307 or (708) 865-8870 • Fax: (708) 865-2941 • www.peerlessmounts.com...
-
Page 2: Table Of Contents
Note: Read entire instruction sheet before you start installation and assembly. WARNING • Do not begin to install your Peerless product until you have read and understood the instructions and warnings contained in this Installation Sheet. If you have any questions regarding any of the instructions or warnings, please call Peerless customer care at 1-800-729-0307. -
Page 3: Parts List
Parts List Description Qty. Part # carriage 201-1020 adapter plate 201-1022-1 5/16-24 x 1/4" set screw 520-9566 M6 x 20 mm serrated washer head socket pin screw 510-9554 M10 x 15 mm socket head screw 520-9262 M6 x 12 mm phillips screw 520-1128 M6 x 20 mm phillips screw 520-9402... -
Page 4: Attaching Adapter Plate To Screen With Vesa 100 Mounting Pattern
Attaching Adapter Plate to Screen with VESA 100 Mounting Pattern WARNING • If screws don't get three complete turns in the screen inserts or if screws bottom out and adapter plate is still not tightly secured, damage may occur to screen or product may fail. Choose hole pattern as shown in figure 2.1. -
Page 5: Attaching Adapter Plate To Screen With Vesa 200 X 200 Mounting Pattern
Attaching Adapter Plate to Screen with VESA 200 x 200 Mounting Pattern WARNING • If screws don't get three complete turns in the screen inserts or if screws bottom out and bracket is still not tightly secured, damage may occur to screen or product may fail. Choose hole pattern as shown in figure 2.3. -
Page 6: Installing Flat Panel Screen On Floor Stand
ISSUED: 2006-02-14 SHEET #: 202-9111-3 (2020-06-04) 6 of 6 © 2006 Peerless Industries, Inc. All rights reserved. Peerless is a registered trademark of Peerless Industries, Inc. All other brand and product names are trademarks or registered trademarks of their respective owners.
