REMKO Smart WP MANAGER Operating Manual page 90

REMKO Smart WP MANAGER
ID Description
Open contact - circulation
ID7210
temp. probe
Short circuit - circulation
ID7211
temp. probe
ID7216 Heat pump malfunction
ID7217 Heat pump malfunction
ID7220 Heat pump malfunction
ID7221 Heat pump malfunction
ID7226 Heat pump malfunction
ID7227 Heat pump malfunction
ID7230 Heat pump malfunction
ID7232 Heat pump malfunction
ID7233 Heat pump malfunction
ID7234 Heat pump malfunction
Communications malfunc-
ID7235
tion
Open contact - mix. cycle
ID7236
inlet temp. probe
Short circuit - mix. cycle
ID7237
inlet temp. probe
Open contact - mix. cycle
ID7238
return flow temp. probe
Short circuit - mix. cycle
ID7239
return flow temp. probe
Connection to the KNX
ID7240
interface
Communications malfunc-
ID7242
tion
Communications malfunc-
ID7243
tion
Communications malfunc-
ID7244
tion
ID7245 Tunnel occupied
90
Desig. Details
Open contact - drinking water circulation temperature
S05
probe
S05 Short circuit - drinking water circulation temperature probe
Malfunction 1st heat pump - the specific fault message can
HP1
be read on the heat pump's display with address 1
Malfunction 2nd heat pump - the specific fault message
HP2
can be read on the heat pump's display with address 2
Malfunction 3rd heat pump - the specific fault message can
HP3
be read on the heat pump's display with address 3
Malfunction 4th heat pump - the specific fault message can
HP4
be read on the heat pump's display with address 4
Malfunction 5th heat pump - the specific fault message can
HP5
be read on the heat pump's display with address 5
Malfunction 6th heat pump - the specific fault message can
HP6
be read on the heat pump's display with address 6
Malfunction 7th heat pump - the specific fault message can
HP7
be read on the heat pump's display with address 7
Malfunction 8th heat pump - the specific fault message can
HP8
be read on the heat pump's display with address 8
Malfunction 9th heat pump - the specific fault message can
HP9
be read on the heat pump's display with address 9
Malfunction 10th heat pump - the specific fault message
HP10
can be read on the heat pump's display with address 10
HP3 Communications malfunction - 3rd Heat pump
S11 Open contact - mixed cycle inlet temperature probe
S11 Short circuit - mixed cycle inlet temperature probe
S12 Open contact - mixed cycle return flow temperature probe
S12 Short circuit - mixed cycle return flow temperature probe
KNX Connection to the KNX IP interface lost
HP4 Communications malfunction - 4th Heat pump
HP5 Communications malfunction - 5th Heat pump
HP6 Communications malfunction - 6th Heat pump
The tunnel with the physical address (PA of the SMT) set
KNX on the controller is already taken by another KNXnet/IP
unit (e.g.: ETS PC) or is not available on the interface
