REMKO Smart WP MANAGER

5.2 Terminal block/legend

Design. Input
PW X
PP
S01 X
S02 X
S03 X
S04 X
S05 X
S06 X
S07 X
S08 X
S09 X
S10 X
S11 X
S12 X
S13 X
S14 X
S15 X
S16 X
S20 X
S21 X
S22 X
S23 X
S24 X
S25 X
S26 X
S27 X
S28 X
S29 X
A01
A02
A03
A04
A10
A11
76
Output Signal
X
X
X
X
X
X
X
Description
Power supply I/O 230V
Power supply for external consumer
Reserve
Reserve
Bottom hot water tank probe
Top hot water tank probe
Circulation return flow temp./impulse
Outside temperature probe
Heating buffer probe
Cooling buffer probe
Unmixed cycle inlet probe
Unmixed cycle return flow probe
1st mixed cycle inlet probe
1st mixed cycle return flow probe
2nd mixed cycle inlet probe
2nd mixed cycle return flow probe
3rd mixed cycle inlet probe
3rd mixed cycle return flow probe
Reserve
Unmixed cycle medium flow rate pulse
1st mixed cycle medium flow rate pulse
2nd mixed cycle medium flow rate pulse
3rd mixed cycle medium flow rate pulse
S0 heat pump electricity meter min. 500 imp./kWh
S0 heat pump household meter min. 500 imp./kWh
Dynamic hygiene function medium flow rate pulse
S0 PV yield min. 500 imp./kWh
S0 PV power supply min. 500 imp./kWh
230V switched pump unmixed cycle
230V switched pump 1st mixed cycle
230V switched pump 2nd mixed cycle
230V switched pump 3rd mixed cycle
230V changeover valve, hot water preparation
230V circulation pump
