Exiting the menu
Provided that no parameter has been selected, the
label "Back" appears on the display, over the left
softkey. Press the left softkey multiple times to get
back to the home screen.
(After a period of inactivity of 150 seconds, the
controller switches back to the home screen auto-
matically.)
Overview
Start animation
Fig. 11: Exiting the menu
3
3.1 Menu structure of the controller
The following information is primarily directed at
system operators. Specialists can find relevant
additional information in the "Operation - Expert
level" chapter.
The following sections introduce the individual
menu items and parameters. You will find a brief
description regarding each menu item. Should you
require a more precise description for the indi-
vidual parameters, then call up the parameter on
the controller and press the
then be displayed
The following diagrams and explanations relate
to the full menu structure, which my differ from
Next view
the menu structure of your own controller. Only
the relevant menu items and parameters are
displayed by the Smart Control, depending
upon which heat generators and functions you
have activated. For example, if no cycle has
been activated, the corresponding menu items
and parameters are not displayed.
Values in square brackets [xx] are the factory
settings. They may be modified by software
updates, and mainly serve in the following
tables to provide an understanding of the func-
tions.
On the Smart Control, the current factory set-
ting is indicated by a green mark.
Operation - User level
key. A help text will
9
