Dell UltraSharp UP2718Q User Manual page 9

Side View
Bottom View
Label Description
1
AC power connector
2
HDMI 1 connector
3 HDMI 2 connector
4 DP connector (in)
5 mDP connector (in)
6 Audio line-out port
USB downstream port
Port with battery icon supports BC 1.2.
9
1 2 3 4 56 7 8
Use
To connect the monitor power cable.
Connect your computer with HDMI cable.
Connect your computer with DP cable.
Connect your computer with DP to mDP cable.
Connect speakers to playback audio coming through
HDMI or DP audio channels.
Only supports 2-channel audio.
NOTE: The audio line-out port does not support
headphones.
WARNING: Excessive sound pressure from
earphones or headphones can cause hearing
damage or loss.
About Your Monitor | 9
