Single monitor connection
Connecting the DP (or mDP) cable
NOTE: Default is DP port. Select input source on monitor to switch to mDP.
Connecting the HDMI cable
Connecting the USB cable
After you have completed connecting the DP-mDP cables, follow the procedure below
to connect the USB 3.0 cable to the computer and complete your monitor setup:
1
a. Connect one computer:
Connect the upstream USB 3.0 port (cable supplied) to an appropriate USB 3.0 port
on your computer.
b. Connect two computers:
Connect the upstream USB 3.0 ports to appropriate USB 3.0 ports on the two
computers. Then use the OSD menu to select between the two USB upstream
sources and input sources. See
NOTE: When connecting two computers to the monitor, the monitor's USB
downstream ports for the keyboard and mouse can be assigned to different input
26
|
Setting Up the Monitor
mDP
HDMI
USB Select
Switch.
DP
HDMI
