Dell UltraSharp UP2718Q User Manual page 42

Icon Menu and
Submenus
PIP/PBP Mode
PIP/PBP (Sub)
PIP Location
USB Select
Switch
Audio
Contrast (Sub)
42 | Operating the Monitor
Description
Adjusts the PBP (Picture by Picture) model to PIP Small, PIP
Large, or PBP. You can disable this feature by selecting Off.
O PIP Small PIP Large
Select between the different video signals that may be
connected to your monitor for the PIP/PBP sub-window.
Select PIP sub-window position.
Use or to browse and
Left, Bottom-Right, or Bottom-left.
Select to switch between the USB upstream sources in PBP
mode.
Allows you to set the audio source from the main window or
the sub-window.
Change Contrast settings of Sub video.
PBP
to select Top-Right, Top-
