1.4

Functional Overview

Table 2: General Feature
Feature
Power supply
Transmission data
GNSS
SMS
SIM interface
Audio features(optional)
Serial interface
USB
Phonebook management
SIM application toolkit
Real Time Clock
Timer function
Physical characteristics
Firmware upgrade
PCM
Temperature range
SIM5360_Hardware Design_V1.01
Implementation
Single supply voltage 3.3～4.2V
Dual-mode UMTS/HSDPA/EDGE/GPRS operation
●
GPRS Class B, multislot class 12 operation, Supports coding scheme:
●
CS1-4
EDGE multislot class 12 operation, Supports coding schemes
●
MSC1-9
UMTS R99 data rates-384 kbps DL/UL
●
Category 6 HSDPA -14 Mbps HSUPA-5.76 Mbps
●
CSD feature: 9.6, 14.4, 64 kbps UL/DL
●
GNSS engine (GPS and GLONASS)
●
Protocol: NMEA
●
Mobile-Assisted mode
●
Mobile-based mode
●
Standalone mode
●
MT, MO, CB, Text and PDU mode
●
SMS storage: SIM card
●
Support transmission of SMS alternatively over CSD or GPRS.
●
User can choose preferred mode.
Support identity card: 1.8V, 3V.
Speech codec modes:
Half Rate (ETS 06.20)
●
Full Rate (ETS 06.10)
●
Enhanced Full Rate (ETS 06.50 / 06.60 / 06.80)
●
AMR (WCDMA)
●
AMR+QCP (GSM)
●
A5/1, A5/2, and A5/3 ciphering
●
Serial Port standard or null modem mode on Serial Port Interface
●
Serial Port can be used to control module by sending AT command
●
Support USB2.0 Slave mode
Support phonebook types: SM, FD, LD, RC, ON, MC.
Support SAT class 3, GSM 11.14 Release 98
Support USAT
Support RTC
Programmable by AT command
Size:30*30*2.9mm
Weight:TBD g
Firmware upgrade over USB interface
Multiplex on GPIOs. 3 kinds of coding formats: 8 bit (υ-law or A-law)
and 16 bit (linear).
Normal operation temperature: -30°C to +80°C
●
