1.4

Functional Overview

Table 2: General Feature
Feature
Power supply
Transmission data
GNSS
SMS
USIM interface
Audio features(optional)
UART interface
USB
Rx-diversity
Phonebook management
USIM application toolkit
Real Time Clock
Physical characteristics
Firmware upgrade
PCM
SIM5360_Hardware Design_V1.06
Implementation
Single supply voltage 3.4～4.2V
Dual-mode UMTS/HSPA+/EDGE/GPRS operation
●
GPRS Class B, multislot class 12 operation, Supports coding scheme:
●
CS1-4
EDGE multislot class 12 operation, Supports coding schemes
●
MSC1-9
UMTS R99 data rates-384 kbps DL/UL
●
Category 6 HSDPA -14.4 Mbps HSUPA-5.76 Mbps
●
CSD feature: 9.6, 14.4, 64 kbps UL/DL
●
GNSS engine (GPS and GLONASS)
●
Protocol: NMEA
●
Mobile-assisted mode
●
Mobile-based mode
●
Standalone mode
●
MT, MO, CB, Text and PDU mode
●
SMS storage: SIM card or ME(default)
●
Support transmission of SMS alternatively over CSD or GPRS.
●
User can choose preferred mode.
Support identity card: 1.8V, 3V.
Support digital audio interface: PCM interface.
Speech codec modes:
GSM : HR/FR/EFR/AMR
●
WCDMA : AMR
●
Echo cancellation and noise suppression.
●
Support full mode or null mode
●
Support AT command
●
Support USB2.0 Slave mode
Support UMTS Rx-diversity.
Support phonebook types: SM, FD, LD, RC, ON, MC.
Support SAT class 3, GSM 11.14 Release 98
Support USAT
Support RTC
Size:30*30*2.9mm
Weight:5.7 g
Firmware upgrade over USB interface
Multiplex on GPIOs.
Used for analog audio function with external codec.
Support long frame sync and short frame sync.
Support 8-bit A-law, μ-law and 16-bit linear data formats.
Support master and slave mode, but must be the master in long frame
sync.
