Sanus Systems SFV49 Assembly Instructions

Step 4: Installing Glass Shelves

Evenly place 4 Glass Protectors (k) along the top, 3 along the middle crossbar and 3 more along the bottom crossbar of the Front Frame
(a) as shown in the Detailed View of Diagram 4. Next, place a Glass protector on the back of each Lower Brace Bars (f). Then, evenly
place 4 Glass protectors on the top of the Back Frame (b). Next, place the Top Glass Shelf (c) on the top of the Front and Back Frame.
Finally, place the two Glass Shelves (d) so they rest on the Lower Brace Bars and the crossbars on the Front Frame. See Diagram 4 for
assistance.
Detailed View
c
k
a
k
crossbar
d
Sanus Systems 2221 Hwy 36 West. St. Paul, MN 55113
800.359.5520 www.sanus.com 8.06.04
Diagram 4
c
k
k
Assembly Instructions for SFV49
Thank you for choosing the Steel Furniture line from Sanus Systems. If you have any questions regarding this or any other Sanus
Systems product, please contact us at 800.359.5520 or visit us at www.sanus.com. Our customer service representatives can assist you
quickly with any issues regarding assembly or missing parts. Check carefully to make sure none of the parts are missing or defective.
Never use defective parts. Replacement parts for products purchased from an authorized dealer will be shipped directly to you. Please
call Sanus Systems before returning products to retail stores.

Parts and Hardware:

(1) Front Frame - a
(1) Back Frame - b
(1) Top Glass Shelf - c
(2) Glass Shelf - d
Sanus Systems 2221 Hwy 36 West. St. Paul, MN 55113
800.359.5520 www.sanus.com 8.06.04
(1) Upper Brace Bar - e
(4) Lower Brace Bar - f
