PARTS LIST
ITEM QTY REFERENCE
31 4 R37, R38, R53, R54
32 2 R40, R41
33 2 R42, R43
34 8 R110-R117
35 3 TP1, TP6, TP7
36 3 T5, T9, T11
37 2 T8, T10
38 1 U2
39 1 U3
40 6 XJ2, XJ5, XJ8, XJ13, XJ14, XJ15
41 2
DEMO MANUAL DC1763A
PART DESCRIPTION
Resistor, Chip, 86.6Ω, 1/16W, 1%, 0603
Resistor, Chip, 49.9Ω, 1/16W, 1%, 0402
Resistor, Chip, 5.1Ω, 1/16W, 1%, 0402
Resistor, Chip, 33k, 1/16W, 1%, 0402
Testpoint, Turret, .094, PBF
Transformer, RF~SMT~1:1 Balun
Transformer, Flux-Coupled Balun
IC, LT1763CS8-1.8 SO8
IC, EEPROM 32KBIT 400khz 8TSSOP
Shunt, 0.079" Center
Stencil (Top & Bottom)
MANUFACTURER/PART NUMBER
Yageo, RC0603FR-0786R6L
Yageo, RC0402FR-0749R9L
Yageo, RC0402FR-075R1L
Yageo, RC0402FR-0733KL
Mill-Max, 2501-2-00-80-00-00-07-0
Macom, MABA-007159-000000
Macom, MABAES0060
Linear Technology, LT1763CS8-1.8#PBF
Microchip, 24LC32A-I/ST
Samtec, 2SN-BK-G
Stencil 1763A
dc1763af
7
