Page 1: Table Of Contents
Illumina DRAGEN Server v3 Site Prep and Installation Guide Introduction Delivery and Setup Facility Requirements Electrical Requirements Environmental Considerations Network Considerations Security and Safety Set Up the DRAGEN Server Configure BMC Configure the Server Network Set Server Time Configure External Storage... - Page 2 Illumina DRAGEN Server v3 Site Prep and Installation Guide Revision History Technical Assistance Document # 1000000097923 v02 For Research Use Only. Not for use in diagnostic procedures.
- Page 3 Illumina DRAGEN Server v3 Site Prep and Installation Guide This document and its contents are proprietary to Illumina, Inc. and its affiliates ("Illumina"), and are intended solely for the contractual use of its customer in connection with the use of the product(s) described herein and for no other purpose.
-
Page 4: Introduction
Illumina DRAGEN Server v3 Site Prep and Installation Guide Introduction This guide provides instructions for setting up the Illumina® DRAGEN™ Server, including preparing your site for installation and operation. You can use the following specifications and guidelines included to prepare your... -
Page 5: Facility Requirements
Illumina DRAGEN Server v3 Site Prep and Installation Guide DRAGEN License USB key Rack mount rails Rack mount screws Facility Requirements Use the specifications and requirements provided in this section to set up your lab space. Equipment Dimensions Measurement Dimension Height 8.8 cm (3.5 in) -
Page 6: Environmental Considerations
Illumina DRAGEN Server v3 Site Prep and Installation Guide Power Cords The DRAGEN Server v3 has international standard IEC 60320 C13 receptacles and is shipped with one region/country-specific power cords. Hazardous voltages are removed from the DRAGEN Server v3 only when the power cords are disconnected from the AC power source. -
Page 7: Network Considerations
Illumina recommends using a user-supplied uninterruptible power supply (UPS). Illumina is not responsible for data loss caused by interrupted power, regardless of whether the DRAGEN Server v3 is connected to a UPS. Standard generator-backed power is often not uninterruptible, so a brief power outage occurs before power resumes. -
Page 8: Security And Safety
Booting in single-user mode allows access to the whole system. Antivirus Software Illumina does not recommend running any virus scanners on the DRAGEN Server v3. Virus scanners often impact the performance of High-Performance Computing (HPC) systems. Restricted Ports and Authentication Outbound Connections lus.edicogenome.com port 80... -
Page 9: Set Up The Dragen Server
Illumina DRAGEN Server v3 Site Prep and Installation Guide Set Up the DRAGEN Server This section provides information on installing the DRAGEN Server v3. Before beginning, make sure that you have all the components and your facility meets the necessary requirements. For more information, see... - Page 10 Illumina DRAGEN Server v3 Site Prep and Installation Guide Extend the slide rail out from the rail assembly. Insert the rail assembly end that was not extended into the server rack brackets. An audible click indicates that the rail assembly is in place.
- Page 11 Illumina DRAGEN Server v3 Site Prep and Installation Guide Install the other rail assembly. 10 Insert screws into each rail assembly to secure the rail assembly to the mounting bracket. 11 Position the mounting bracket so the green edge is located at the front of the server.
- Page 12 Illumina DRAGEN Server v3 Site Prep and Installation Guide 14 Make sure that all screws are fully seated. 15 Extend the slide rails out from the rail assembly. 16 Facing the front of the rack, lift the server between the slide rails.
-
Page 13: Configure Bmc
Illumina DRAGEN Server v3 Site Prep and Installation Guide Figure 1 Rear of DRAGEN Server v3 Power supply inlet RJ45 10 GB Port 2 RJ45 10 GB Port 1 10 GB SFP+ Port 2 10 GB SFP+ Port 1 HDMI Port (monitor) Install the DRAGEN Server v3 License You can activate the DRAGEN Server v3 by installing the USB license key as follows. -
Page 14: Configure The Server Network
Illumina DRAGEN Server v3 Site Prep and Installation Guide To use a static IP address, do as follows. Enter the following command: ipmitool lan set 1 ipsrc static b To set the IP address, enter: ipmitool lan set 1 ipaddr <IP address>... -
Page 15: Set Server Time
Illumina DRAGEN Server v3 Site Prep and Installation Guide Set Server Time Set Server Time to Local Time Zone Log in as root. Check if the current server time reflects the local time zone using the date command. Enter: date Check for a nearby city with the correct time zone using the timedatectl list-timezones command. -
Page 16: Configure External Storage
Illumina DRAGEN Server v3 Site Prep and Installation Guide :wq! To restart the chrony daemon, enter: systemctl restart chronyd Check the health of the local time server. Enter: timedatectl 10 Make sure that DRAGEN can synchronize with the local NTP server using the ntpdate command. -
Page 17: Activate Dragen Software License
Offline Servers For servers not connected to the internet, Illumina Customer Service provides the necessary license files to activate the license on the server locally. If you have not received these license files, email Illumina Customer Service at customerservice@illumina.com. After you have the necessary license files, activate your DRAGEN Software license as follows. - Page 18 Illumina DRAGEN Server v3 Site Prep and Installation Guide Confirm that the license has been updated. Enter: /opt/edico/bin/dragen_lic Running the System Check After turning on the server, make sure that your DRAGEN Server v3 is functioning properly by running the following self-test script: /opt/edico/self_test/self_test.sh...
-
Page 19: Install The Dragen Software
If the hardware upgrade process is interrupted, perform the software install steps again. If the DRAGEN Software is not functional after the second install attempt, contact Illumina Technical Support. Use the following halt command to power the server off and on: A reboot command does not update the hardware version. -
Page 20: Shut Down The Server
Wait a few minutes until the server comes to a complete shutdown. Advanced Exchange Because the DRAGEN Server v3 has no serviceable parts, Illumina uses an Advanced Exchange replacement model to rectify issues that cannot be resolved remotely. Advanced Exchange replaces a damaged or defective DRAGEN Server v3 with a replacement server. To minimize downtime, you receive the replacement system before shipping back the original. - Page 21 Illumina DRAGEN Server v3 Site Prep and Installation Guide Disconnect all power and Ethernet network cords from the back of the server. Disconnect monitor, keyboard, mouse, and cables from the server. Uninstall server from the rack. Package the Server Clear adequate space in the lab for the server and packaging.
- Page 22 If your facility has daily deliveries scheduled with UPS, give the labeled shipping box to the driver. If your facility does not have daily deliveries with UPS, notify Illumina Customer Service so that they can schedule the return shipment for you.
-
Page 23: Server Specifications
Illumina DRAGEN Server v3 Site Prep and Installation Guide Server Specifications This section includes additional specifications for the DRAGEN Server v3. Component Specifications Dual Intel® Xeon® Gold 6226 2.7 GHz, 12 C/24 T System Memory 256 GB DDR4 Scratch Drive 6.4 TB NVMe U.2 SSD... - Page 24 Illumina DRAGEN Server v3 Site Prep and Installation Guide Revision History Document Date Description of Change Document # September Updated the following information: 2020 • Shipping box components. 1000000097923 v02 • Equipment dimensions. • Power specifications. • Server port locations.
- Page 25 00806651752 United Kingdom +44 8000126019 +44 2073057197 Other countries +44.1799.534000 Safety data sheets (SDSs)—Available on the Illumina website at support.illumina.com/sds.html. Product documentation—Available for download from support.illumina.com. Document # 1000000097923 v02 For Research Use Only. Not for use in diagnostic procedures.
- Page 26 Document # 1000000097923 v02 Illumina 5200 Illumina Way San Diego, California 92122 U.S.A. +1.800.809.ILMN (4566) +1.858.202.4566 (outside North America) techsupport@illumina.com www.illumina.com For Research Use Only. Not for use in diagnostic procedures. © 2020 Illumina, Inc. All rights reserved.
