- Page 1 PRESENTED BY JPBOWLIN.COM 817.332.8116 J.P. Bowlin is a quality-driven Calibration Company that has provided calibration, repair and sales of all types of weighing and measurement products since 1931.
- Page 2 98648-004-76 Sartorius IS 64 FEG-S0CE Weighing Platform Installation and Operating Instructions...
-
Page 3: Table Of Contents
Operating Limits "Certificate on "Testing by the PTB Maximum Overload Capacity Declarations of Conformity Shock Resistance "EC Verification” - A Service Offered by Sartorius General Instructions for Integration into Conveyor Systems Accessories (Options) Preload Range (Zero-Setting Range) Configuring the Weighing Platform... -
Page 4: General View Of The Weighing Platform
General View of the Weighing Platform No. Designation Load plate Manufacturer's label for a weighing platform verifiable or verified as a legal measuring instrument Leveling feet Level indicator Connecting cable (interface port/power supply) Blank for power supply cable gland (optional) -
Page 5: Warranty
With this Sartorius IS weighing platform, you have acquired a high-quality weighing instrument that features advanced technology. As a rule, you will be using this weighing platform as part of a modular weighing System. Please read through these installation and operating instructions carefully before operating your new weighing platform. -
Page 6: Safety Instructions
Safety Instructions Only authorized service technicians trained by Sartorius are allowed to open the weighing cell and A/D Converter enclosures, which are located inside the weighing platform, for repair work according to Sartorius Standard operating procedure. Before opening the weighing cell or A/D Converter enclosure, make sure to... -
Page 7: Installation Instructions
Installation Instructions Sartorius dealers or service technicians, who have received special training, will help you set up the weighing platform and show you how to operate it. Ambient Conditions Choose a suitable place to set up the weighing platform. Avoid exposing the weighing platform to the following ambient conditions: —... -
Page 8: Ip67 Protection
IP67 Protection The IP67 protection of the weighing platform is guaranteed only if the platform is in original factory condition. In conformance with the IP67 protection rating, the weighing platform will remain leaktight for 30 minutes if immersed at a depth of 1 meter (approx. 3 ft.). The IP67 protection of the weighing platform is ensured only under the following conditions: —... -
Page 9: Getting Started
Getting Stared Unpacking the Weighing Platform — Remove the weighing platform and separate load plate from the packaging — Remove the plastic bags, packaging strips and foam material Transport Locking Devices Set up the weighing platform in the vicinity of your work area, remove the load plate (1), and remove the red plastic caps. -
Page 10: Leveling The Weighing Platform
Before operating the scale, connect the following cables and completely assemble the components listed below: — interface cable to a Sartorius isi industrial terminal or a Computer with special Software — separate power cable for power supply via a Sartorius AC adapter (optional) —... -
Page 11: Connecting The Weighing Platform
Cable Lengths: Since you can choose to power the weighing platform via the interface port of the Sartorius isi industrial terminal or a separate power supply unit, there are a few restrictions that apply to the cable lengths between these components. - Page 12 Standard you use, please contact your local Sartorius dealer or office. To use a main feeder cable from the ceiling or to mount a CEE plug, you will have to make arrangements inside your facilities for installation of such cable equipment.
-
Page 13: Safety Precautions
Installation requirements of your country. Safety Precautions The Sartorius power supply rated to Industrial Class 2 can be plugged into any electrical outlet without requiring any additional safety precautions. The ground or earth terminal is connected to the platform housing, which can be additionally grounded/earthed, if required. -
Page 14: Warm-Up Time
Warm-up Time The weighing platform will need to warm up for at least 30 minutes after initial connection to the power supply (or after a relatively long period without power connection). Preparing the Weighing Platform for Verification as a Legal Measuring Instrument in the EU*: After initially connecting the weighing platform to the power supply (or after a relatively long power... -
Page 15: Operating Limits
Operating Limits Maximum Overload Capacity Sartorius weighing platforms are built so that occasionally loading them beyond their maximum weighing capacity will not damage them in any way. The maximum overload capacity of this IS model is 130 kg. Shock Resistance Even though Sartorius weighing platforms feature a highly rugged construction, there are some limits. -
Page 16: General Instructions For Integration Into
General Instructions for Integration into Conveyor Systems The IS weighing platform is suitable for installation in conveyor Systems. Follow the general instructions given below and refer to the "Dimensions (Scale Drawings)" to meet the requirements for such installation. Any moving or rotating parts intended to be permanently attached to the load plate must be designed so that they cannot affect the weighing results. -
Page 17: Configuring The Weighing Platform
For this reason, final configuration of your Sartorius Modular Technology equipment is possible only at your dealers or your particular facilities. -
Page 18: Specifications Chart
Specifications Chart Access the configuration menu of the connected suited Sartorius terminal to set the code for the group of specifications of your choice. You must set one of the appropriate codes before verification of the platform as a legal measuring instrument. -
Page 19: General Technical Specifications
DIN 40050/IEC 529 IP 67 Net weight, approx. Requirements for power connection Via AC adapter, ING2: 230 V or 115 V (to be (optional) connected by your dealer or Sartorius service technician only) Frequency 48 – 63 Power consumption, VA, approx. -
Page 21: Dimensions (Scale Drawings)
Dimensions (Scale Drawings) IS 64 FEG-S0CE Area for attaching conveyor components; fasteners may protrude below by 10 mm max. All dimensions are given in millimeters... -
Page 22: Pin Assignment Chart
Pin Assignment RS-485,3-m Cable Male Connector: Type C091 D, 1 2-pin round connector with threaded locking ring, Amphenol (IP67) Pin Assignment RxD-TxD-N Not Connected Not Connected Not Connected Signal GND Menu Access Switch for Calibration/ Adjustment (routed externally) VCC (24-V Power Supply) Not Connected GND (24-V Power Supply: GND (24-V Power Supply:... -
Page 23: Troubleshooting Guide
Troubleshooting Guide (For Problems That You Can Fix Yourself Problem Possible Causes Solution No segments appear on the display - No line current is available - Check the power supply - The AC adapter is not plugged in - Plug the AC adapter into the platform and into an electrical outlet - The weighing platform has been in... - Page 24 - Adjust/calibrate the weighing obviously wrong adjusted/calibrated before weighing platform - The weighing platform is tilted - Level the weighing platform as described in the instructions lf any other errors occur, please contact your nearest Sartorius service center or your dealer...
-
Page 25: Care And Maintenance
Care and Maintenance Servicing Regular servicing by a Sartorius technician will extend the service life of your weighing platform and ensure its continued weighing accuracy. Sartorius can offer you service contracts, with your choice of regular maintenance intervals ranging from 1 month to 2 years. -
Page 26: Safety Inspection
- the power supply has been stored for a relatively long period under adverse conditions In this case, notify your nearest Sartorius Service Center or the International Technical Support Unit based in Goettingen, Germany. Only service technicians who are authorized by Sartorius and who have access to the required service manuals are allowed to perform maintenance and repair work on the equipment. -
Page 27: Manufacturer's Declaration
Therefore, a legal weighing instrument can consist of the following: - a Sartorius isi industrial terminal + 1 to 3 weighing platforms - a Sartorius isi industrial terminal + 1 weighing platform +up to 2 further EC- or nationally type-approved weighing instruments. -
Page 28: Effect Of The Preload On The Acceptability For Verification In The Eu
To have your weighing platform verified, you must change the preload setting before verification only. The legal basis permitting Sartorius to perform initial verification is constituted by the following: 1 ) EC Council Directive no. 2009/23/EC on non-automatic weighing instruments, which has been applicable within the harmonized Infernal Market of the European Union since 1 January 1993;... - Page 29 Computer, or a similar device Information Concerning the EC Machinery Directive Sartorius balances, scales and weighing platforms are not machines in the sense of the EC Machinery Directive; however, as individual Instruments they meet the safety requirements of this Directive.
-
Page 32: Certificate On "Testing By The Ptb
Important Note: The operator shall be responsible for any modifications to Sartorius equipment and for any connections of cables or equipment not supplied by Sartorius and must check and, if necessary, correct these modifications and connections. On request, Sartorius will provide information on the minimum operating specifications (in accordance with the Standards listed above for defined immunity to interference). - Page 33 Council Directive 2009/23/EC "Non-Automatic Weighing Instruments" For the respective Declaration of Type Conformity for weighing instruments that have been verified by Sartorius for use as legal measuring instruments and that have an EC Type-Approval Certificate, see page 33 or next page.
-
Page 35: "Ec Verification - A Service Offered By Sartorius
For Information on verification and legal regulations currently applicable in your country, and to obtain the names of the persons to contact, please contact your local Sartorius office, dealer or service center as indicated on the following page. * = in accordance with accreditation received by Sartorius... -
Page 36: Accessories (Options)
Accessories (Options) Order No.: Data interface port with 3-m cable (IP67, RS-485) and 1 2-pin round connector (electrically isolated) YD0511S Data interface port with 3-m cable (IP67, RS-232C/ RS 423) and 1 2-pin round connector (electrically isolated) YD0521S Data interface port with 6-m cable (IP67, RS-485) and 1 2-pin round connector (electrically isolated) YD0531S Extension cable to connect an isi terminal... - Page 37 (use as a test weight only for weighing platforms verified as legal measuring instruments) Configuration diskette for the IS weighing YAD 01 IS platform (PC, DOS), without interface cable For ordering customized cables and accessories, contact your local Sartorius office or dealer...
- Page 41 Selecting and Attaching ID Plates The ID plate is to be selected and attached according to the specification block (configuration of scales) and the display and control unit (terminal). For details of how to position the ID plate on the scales or tag holder, refer to the instructions in "Plates and Markings".
- Page 45 Sartorius Weighing Technology Weender Landstraße 94-108 37075 Göttingen, Germany Phone +49.551.308.0 Fax +49.551.308.3289 www.sartorius-mechatronics.com Copyright by Sartorius , Goettingen, Germany. All rights reserved. No part of this publication may be reprinted or translated in any form or by any means without the prior written permission of Sartorius.
