- Page 1 Installation Instructions Sartorius TopMix Model TM01-X Electronic Paint-mixing Weighing System 98648-011-50...
-
Page 2: General View Of The Equipment
General View of the Equipment 1 Terminal/display and control unit (TM01-X) 11 Connector for monitor (VGA test monitor, 2 LC-display (VGA) 800x600 pixels) outside the hazardous area 3 QWERTY keypad 12 Connector for the VGA video cable 4 Mouse (YCC01-0039M3; length: 3 m). Connects the 5 Connector for equipotential bonding Ex-link box to a standard PC outside the conductor... -
Page 3: Table Of Contents
Contents Intended Use 2 General View of the Equipment The Sartorius TopMix paint-mixing weigh- 3 Intended Use ing system consists of the operator termi- 4 Warnings and Safety Precautions nal/control panel (TM01-X, monitor and 6 Getting Started keypad) for installation in a hazardous area... -
Page 4: Warnings And Safety Precautions
EN 50020: 2004 The TopMix can be operated with – Use the dust cover supplied to protect intrinsically safe Sartorius weighing the equipment from splashes of paint. instruments (e.g., PMA7500-X) in Zone 1 Observe the cleaning instructions when hazardous areas (see “Verification of cleaning the equipment. - Page 5 Repair work may be performed only your country. Ask your local Sartorius by authorized service technicians who office or dealer for information on the have been trained by Sartorius and who legal regulations applicable in your follow Sartorius’ standard operating pro- country.
-
Page 6: Getting Started
Getting Started Unpacking the Equipment § After unpacking the equipment, check it immedi- ately for any visible sign of damage resulting from rough handling during shipment. $ If any sign of damage is visible, refer to the section entitled “Safety Inspection” in the chapter entitled “Care and Maintenance.”... - Page 7 – Use only cabling and extensions approved by Sartorius, as these are made in accordance with the restrictions on permissible cable lengths imposed by both the capacitance and inductivity values (see the “Schedule to EC Type-Examina-...
- Page 8 (e.g., display remains blank, no display backlighting, etc.) due to damage dur- ing transport, disconnect the equipment from power and notify your nearest Sartorius Service Center. Before connecting or disconnecting data cables or control lines to or from the device, make sure all equipment is disconnected from power.
-
Page 9: Installing The Topmix System
Installing the TopMix System § Connect the TopMix—Ex-link cable (YCC01-0038M20; length: 20 m) to the terminal. Tighten the connector. § Connect the TopMix—VGA video cable (YCC01-0037M20; length: 20 m) to the terminal. Tighten the fastening screws. § Connect the weighing instrument (e.g., PMA scale) using the TopMix—PMA series cable (YCC01-0041M3). - Page 10 § Connect the equipotential bonding conductor. Use grounding cable (not included in delivery) to connect the grounding terminals on all devices to the equipotential bonding conductor of the power supply in use at the place of installation. The dimensions of the grounding cable are speci- fied in national regulations for electrical installa- tions.
- Page 11 § Connect the TopMix—VGA video cable (YCC01-0037M20; length: 20 m) to the Ex-link box (YCO09-Z) (Ex side). Tighten the fastening screws. § USB port (see illustration): Connect the TopMix—PC USB cable (YCC01- 0040M3; length: 3 m) for a standard computer to the Ex-link box outside the hazardous area (PC side).
- Page 12 § Monitor connection: VGA control monitor, 800x600 pixels, outside the hazardous area (PC side). Computer setting: high color (16-bit) § Connect the equipment to power (PC side). Note: Observe the warnings and safety precautions included in these instructions. Note: § The Ex-link box (YCO09-Z) can be mounted on the wall or on the underside of the table or workbench.
- Page 13 Connecting the System to AC Power The equipment is powered through the power cord supplied. The Ex-link box (YCO09-Z) has a built-in AC adapter for operation with a power supply between 90 and 264 V and a frequency of 47 to 63 Hz. If the line voltage or frequency exceeds these limits, or if the plug on the cable does not match the standard used in your area, please contact your supplier for assistance.
-
Page 14: Care And Maintenance
Care and Maintenance Service Cleaning Regular servicing by a Sartorius techni- Make sure no liquid enters the equip- cian will ensure continuous correct ment housing. functioning of your equipment. Sarto- Do not use aggressive cleaning agents. rius offers service contracts with regular... - Page 15 Y Year 1 2000–2006 Note: 2 2007–2013 The operator shall be responsible for any 3 2014–2020 modifications to Sartorius equipment and 4 2021–2027 must check and, if necessary, correct these 5 2028–2034 modifications. On request, Sartorius will 6 2035–2041 provide information on the minimum oper- 7 2042–2048...
-
Page 17: Specifications
Specifications TopMix TM01-X with Ex-link box (YCO09-Z) Model TM01-X Allowable ambient operating temperature range °C +5 to +40 (41° to 104°F) Housing dimensions (WxDxH): TopMix display and control unit 420 x 444 x 396 Ex-link box 375 x 175 x 73 Net weight: TopMix display and control unit, approx. -
Page 18: Declaration Of Conformity
Declaration of Conformity... - Page 23 !" # (see also page 3) $%& ' ( )&*+ , $%& ' + , - -. '/ --0 -1 -. '/ - 2-0 SARTORIUS AG Cable 2) Video in 15 pole Type YCC01-0037M.. 3 &03 SARTORIUS AG D-SUB 2) Video out 3 &4 5 socket Cable 2) AC Supply 12 pole Type YCC01-0038M..
- Page 24 &# (see also page 3) $%& ' ( )&*+ , $%& ' + , - -. '/ --0 -1 -. '/ - 2-0 SARTORIUS AG Cable 2) Video in 15 pole Type YCC01-0037M.. 3 &03 SARTORIUS AG D-SUB 2) Video out 3 &4 5 socket Cable 2) AC Supply 12 pole Type YCC01-0038M.. round...
- Page 25 !" # For - installation: Not for esters and alkanes atmospheres! For -1 installation: No restrictions on gases of group IIA and IIB. The Model YCO09-Z must not be connected to any device that uses or generates in excess of 250Vrms or 250Vdc.
- Page 26 Sartorius AG Weender Landstrasse 94–108 37075 Goettingen, Germany Phone +49.551.308.0 Fax +49.551.308.3289 www.sartorius.com Copyright by Sartorius AG, Goettingen, Germany. All rights reserved. No part of this publication may be reprinted or translated in any form or by any means without the prior written permission of Sartorius AG.
