Elo TouchSystems 15D1 Touchcomputer Quick Installation Manual page 2
Installing the magnetic stripe reader
Hide thumbs
Also See for 15D1 Touchcomputer:
- User manual (53 pages) ,
- Specifications (2 pages) ,
- Quick installation manual (2 pages)
Advertisement
1
2
5 3
urn
power to the
T
off the
computer.
touch
Remove the existing
cover for the MSR port
on the back side of the
display head.
Connect the MSR to
the existing connector (USB).
4
5
6
Slide the MSR onto the
mounting hooks.
Secure the MSR onto the
display head with one
screw from the MSR Kit.
Turn on the touchcomputer.
