Enco Control Technical Description page 23

Serial communication interface connectors and expansion connector
Fig. 19.
Table 12. Numbering of terminals
Terminal
number
Serial interface connector J28 (type RJ11)
J28.1
J28.2
J28.3
J28.4
J28.5
J28.6
Serial interface connector J27 (type RJ11)
J27.1
J27.2
J27.3
J27.4
J27.5
J27.6
Expansion connector J29 (type RJ11)
J29.1
J29.2
J29.3
J29.4
J29.5
J29.6
Ethernet connector J21 (type RJ45)
•
Kulautuvos g. 45a , LT-47190 Kaunas
Description
Port 1, signal TX (RS232)
Port 1, GND
Port 1, signal RX (RS232)
Port 2, GND
Port 2, TX (TTL)
Port 2 RX (TTL)
Port 0, signal TX (RS232)
Port 0, GND
Port 0, signal RX (RS232)
-
-
-
-
GND
-
GND
RS485 B
RS485 A
• •
