- Page 1 No.19S019-01 PoCL Camera Link Monochrome / Color CMOS Camera STC-APB503PCL (5.0M / Monochrome) STC-APC503PCL (5.0M / Color) Product Specifications and User’s Guide STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide...
-
Page 2: Table Of Contents
Table of Contents Product Precautions .................... 3 Warranty ........................ 3 Specifications ....................... 4 Electronic Specifications ......................4 Spectral Sensitivity Characteristics ..................6 3.2.1 STC-APB503PCL ..........................6 3.2.2 STC-APC503PCL ..........................6 Mechanical Specifications ....................... 7 Environmental Specifications ....................7 Common Specification......................8 3.5.1 Camera Link Connector ........................ - Page 3 No.19S019-01 Revisions History ....................28 STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide...
- Page 4 This will case of electrification or fire. Do not use Camera Link un-supported cable and board. There is a risk of malfunction if the camera connects with wrong environment and turn on the camera. STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide...
- Page 5 It is turn off the camera when maintaining or This will cause of fire, electrification or inspecting the camera. malfunction. This will cause of electrification. [Disposal] Caution It is necessary to dispose as industrial waste. STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide...
-
Page 6: Product Precautions
Exchange or repair the malfunction camera if the malfunction is occurred by our responsibility. “Warranty” mean is warranty for the delivered camera itself. Please accept the induction damage by the camera malfunction is not included. STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide... -
Page 7: Specifications
0 to 2,004 lines Multi ROI Gamma x2 vertical / Off Binning Decimation Image Flip Defective Pixel Correction Up to 256 points Auto Image Auto Exposure Control Auto Gain Auto White Balance Default: Bold STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide... - Page 8 0 dB Light Source Light Box (White) Color temperature 5,100K White Balance Optimum Lens Electrical Shutter 1/30 seconds F on Lens F5.6 Black Level Optimum Target Luminance IM-600 (Topcon) Gamma Factory Setting STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide...
-
Page 9: Spectral Sensitivity Characteristics
No.19S019-01 Spectral Sensitivity Characteristics 3.2.1 STC-APB503PCL 3.2.2 STC-APC503PCL STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide... -
Page 10: Mechanical Specifications
If the camera has a mounted lens and a tripod with an aluminum plate, this could decrease the camera housing temperature for the heat dissipation. Taking these steps will maintain the heat rating of the electronic components of the camera. Upper side of camera Measuring point STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide... -
Page 11: Common Specification
PoCL. Pin Assignment Pin No. Signal Name Pin No. Signal Name +12V Xclk- Xclk+ SerTC+ SerTC- SerTFG- SerTFG+ CC1-(TRG) CC1+(TRG) CC2+ CC2- CC3- CC3+ CC4+ CC4- +12V STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide... -
Page 12: Power-I/O Connector
Power-I/O connector: 2pin (*1) The power consumption when the high voltage trigger signal input to the input port. (*2) The power consumption for the output port has to be managed less than 10 mA. STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide... -
Page 13: Input Signal Circuit
3.5.4 Output signal circuit Camera +3.3V +3.3V 6Pin Conector 47k Ω Pin. 3 or 4 or 5 Camera User Output output 3,4, Voltage 0 to (from +3.3V DC FPGA) 100 Ω TC7WH241FK STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide... -
Page 14: Dimensions
No.19S019-01 Dimensions Unit: mm STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide... -
Page 15: Sensor Information
The Bayer pattern array on the sensor Pixe11 of Pixe12 of Data Data Pixel21 of Pixe22 of Data Data Pixel (m, n) of Data: nth pixel of the mth line being transferred STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide... -
Page 16: Camera Output Timing Charts
1 CLK = 31.25 nseconds 1164 CLK LVAL One horizontal (1H) DVAL FVAL 2CLK 2CLK Video out (Tap1) Video out (Tap2) Video out (Tap ３ ) 300 CLK 864 CLK Horizontal blanking Video output STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide... -
Page 17: Tap (1X2-1Y) / Binning
1 CLK = 31.25 nseconds 1395 CLK LVAL One horizontal (1H) DVAL 864 CLK FVAL 2CLK 2CLK Video out (Tap1) Video out (Tap2) Video out (Tap ３ ) 531 CLK 864 CLK Horizontal blanking Video output STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide... -
Page 18: Vertical Timing
Video output active term blanking blanking LVAL DVAL 8.1.2 Binning 1 H = 43.61 µseconds One vertical (1V) FVAL 972H Video out Vertical Vertical Video output active term blanking blanking LVAL DVAL STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide... -
Page 19: Camera Function Mode
I n t e r n a l E x p o s u r e T i me S e n s o r E x p o s e V i d e o Ou t STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide... -
Page 20: Pulse Width Trigger Mode
Pulse width trigger mode (Global Reset Release [GRR]) ｔROW ： Horizontal cycle（ROW Time） 8×ｔROW Trigger （Positive Edge） tROW 1st Row Exposure Exposure 1st Row 2nd Row Exposure Exposure 2nd Row FVAL LVAL Video Out STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide... -
Page 21: Edge Preset Trigger Mode
SW ： Exposure time （20 to 23H shutter speed settings) SW(usec.) Trigger （Positive Edge） tROW 1st Row Exposure Exposure 1st Row 2nd Row Exposure Exposure 2nd Row 8 × tROW FVAL LVAL Video Out STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide... -
Page 22: Communication Protocol Specifications
Communication method UART (RS232C standard compliant), Binary communication Communication settings 9,600bps / 38,400bps / 57,600bps / 115,200bps Baud rate Data bit 8bits Parity None Stop bit 1bit Flow control None STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide... -
Page 23: Communication Format
Send the read command to read the 00H address data of the register 02, 00, 00, 01, 00, 03 SOF, (Device code / Read / Register), Command code, Data length, Data, EOF The return command 02, 01, 00, 03 STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide... -
Page 24: Camera Control Commands
Vertical ROI_A Start line (16bits: D[15..8]) 92 - 9FH Reserved Vertical ROI_A Effective lines (16bits: D[7..0]) 1,944 1 to 2,005 Vertical ROI_A Effective lines (16bits: D[15..8]) A2 - AFH Reserved (*1) Only available for the color model STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide... - Page 25 White Balance GR gain (15bits: D[14..8]) (*1) 0 to 127 White Balance GB gain (15bits: D[14..8]) (*1) 0 to 127 Camera function mode 6 (8bits: D[7..0]) Reserved (*1) Only available for the color model STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide...
-
Page 26: Description Of The Camera Control Commands (Bank Number: 00H)
UART [7..0] Sets the communication mode. D7 to D2 No Function Sets always as "000000" D1 to D0 Communication Mode 00: 38,400 bps 01: 9,600 bps 10: 57,600 bps 11: 115,200 bps STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide... - Page 27 Always set as “00000” D2 to Test Pattern 0: Off (Video output) 1: Gray scale image 2: Lamp image 3: White image 4: Signal output level 5: Color bar image Others: Black image STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide...
- Page 28 [Pixel defect Y position (Set)] Default data: PDC_WY [15..0] = 0, Data range: 0 to 1,944 PDC_WY [7..0] Sets the Y (vertical) coordinate position of the defect pixel for set the position. D5H: PDC_WY [15..8] STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide...
- Page 29 [The camera function mode] Default data: MOD6 [7..0] = 2 MOD6 [7..0] Sets the camera TAP number for each setting. D7 to D0 TAP Configuration 1: 2TAP 2: 3TAP Others: No Function STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide...
-
Page 30: Command Sequence For The Data Saves To The Eeprom
Note.3) When save the data of the multiple commands, which is not continuous commands, to the EEPROM, it is necessary to operate the multiple sets of above sequence (1) to 4)). e.g. Multiple commands: “10H, 13H, 19H and 1BH” or “20H, 23H and 25H”. STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide... - Page 31 Note 2019/01/28 New Document 2019/02/27 Revised Added trademark information Camera Link (including PoCL) is trademark of AIA. Other company names and product names in this document are trademarks of their respective owners. STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide...
- Page 32 No.19S019-01 19F, Ebina Prime Tower 9-50, Chuo 2 chome Ebina-city, Kanagawa 243-0432 Japan TEL 81-46-236-6660 FAX 81-46-236-6661 URL http://www.sentech.co.jp/ STC-APB503PCL / STC-APC503PCL Product Specifications and Use’s Guide...
