Omron FJ-300 Series Instruction Manual

Omron FJ-300 Series Instruction Manual

Pc vision system

Advertisement

Quick Links

PC Vision System
FJ-300_/FJ-305_/FJ-H300_/FJ-H305_
FJ-300_-10/FJ-305_-10/FJ-H300_-10/FJ-H305_-10
INSTRUCTION MANUAL
Thank you for selecting the FJ Series PC Vision System.
This manual explains how to use the FJ Series PC Vision System.
When using the FJ Series PC Vision System, make sure to observe the following:
• The FJ Series PC Vision System must be operated by personnel knowledgeable
in electrical engineering.
• To ensure correct use, please read this manual thoroughly to deepen your
understanding of the product.
• Please keep this manual in a safe place so that it can be referred to whenever necessary.
* The meaning of "_" in model is described below.
0:NPN I/O type
TRACEABILITY INFORMATION:
Representative in EU:
Omron Europe B.V.
Wegalaan 67-69 2132 JD Hoofddorp,The Netherlands
Manufacturer:
Omron Corporation,
Shiokoji Horikawa,Shimogyo-ku, Kyoto 600-8530 JAPAN
Ayabe Factory
3-2 Narutani, Nakayama-cho, Ayabe-shi, Kyoto 623-0105 JAPAN
The following notice applies only to products that carry the CE mark:
Notice:
This is a class A product. In residential areas it may cause radio interference,
in which case the user may be required to take adequate measures to reduce
interference.
© OMRON Corporation 2011 All Rights Reserved.
FJ Series
5:PNP I/O type
(SETUP)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FJ-300 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Omron FJ-300 Series

  • Page 1 The following notice applies only to products that carry the CE mark: Notice: This is a class A product. In residential areas it may cause radio interference, in which case the user may be required to take adequate measures to reduce interference. © OMRON Corporation 2011 All Rights Reserved.
  • Page 2: Read And Understand This Document

    PRODUCTS, WHETHER SUCH CLAIM IS BASED ON CONTRACT, WARRANTY, NEGLIGENCE, OR STRICT LIABILITY. In no event shall responsibility of OMRON for any act exceed the individual price of the product on which liability is asserted. IN NO EVENT SHALL OMRON BE RESPONSIBLE FOR WARRANTY, REPAIR, OR OTHER CLAIMS REGARDING THE PRODUCTS UNLESS OMRON’S ANALYSIS CONFIRMS THAT THE PRODUCTS...
  • Page 3: Meanings Of Signal Words

    Do not attempt to dismantle, repair, or modify the product. • Should you notice any abnormalities, immediately stop use, turn OFF the power supply, and contact your OMRON representative. • Do not touch fluorescent or halogen lights while the power is ON or immediately after the power is turned OFF.
  • Page 4: Precautions For Correct Use

    When mounting a box-shaped controller (FJ-305_/FJ-H305_/FJ-305_-10/FJ-H305_-10) at its base, it will short-circuit to the FG of your device since the bottom surface is connected to the SG (0V). In order to avoid this, we provide insulating spacers. Please consult your OMRON representative for information. Camera cable...
  • Page 5: Confirming Package Contents

    ● Noise Resistance • Do not install the product in a cabinet containing high-voltage equipment. • Do not install the product within 200 mm of power cables. ● Component Installation and Handling • Touching Signal Lines To prevent damage from static electricity, use a wrist strap or another device for preventing electrostatic discharges when touching terminals or signal lines in connectors.
  • Page 6: Basic Configuration

    FZ-VM (2 m, 5 m) camera cable FZ-VSL2 (15m) Camera Power Supply Detects workpieces as images. Recommended Model Intelligent camera Automatic focus camera By OMRON Corporation FZ-SLC15/FZ-SLC100 FZ-SZC15/FZ-SZC100 S8VS-12024 Peripheral Device Standalone camera Intelligent compact camera FZ-SC/FZ-S/FZ-SC2M FZ-SQ010F/FZ-SQ050F USB memory...
  • Page 7: Component Names And Functions

    Component Names and Functions ● LCD integrated type FJ-3000/FJ-3005/FJ-H3000/FJ-H3005 Left-side view Front view Right-side view 9 RS-232C/RS-422 connector 67 Power/ 4 I/O connector ground terminal (control lines, data lines) 8 Monitor connector (analog RGB) A Ethernet connector 5 Camera connector 0 USB connector 1 POWER LED 2 RUN LED...
  • Page 8 FZ-VM (2 m, 5 m) camera cable FZ-VSL2 (15m) Camera Power Supply Detects workpieces as images. Recommended Model Intelligent camera Automatic focus camera By OMRON Corporation FZ-SLC15/FZ-SLC100 FZ-SZC15/FZ-SZC100 S8VS-18024 Peripheral Device Standalone camera Intelligent compact camera FZ-SC/FZ-S/FZ-SC2M FZ-SQ010F/FZ-SQ050F * USB memory...
  • Page 9 Component Names and Functions ● LCD integrated type FJ-3000-10/FJ-3005-10/FJ-H3000-10/FJ-H3005-10 Left-side view Front view Right-side view 9 RS-232C/RS-422 67 Power/ connector ground 4 I/O connector terminal (control lines, data lines) 8 Monitor connector (analog RGB) A Ethernet connector 5 Camera connector 0 USB connector 1 POWER LED 2 RUN LED...
  • Page 10: Parallel Interface

    Parallel Interface NPN I/O type FJ-3000/FJ-3050/FJ-H3000/FJ-H3050 FJ-3000-10/FJ-3050-10/FJ-H3000-10/FJ-H3050-10 Internal Specifications [Input] signals: STEP0/ENCTRIG_Z0, STEP1/ENCTRIG_Z1, [Input] signals: RESET, DI0 to DI7, DSA0, DSA1 ENCTRIG_A0 to 1, ENCTRIG_B0 to 1 Input voltage 12 to 24 V DC ±10 % Input voltage 12 to 24 V DC ±10 % ON current *1 5 mA min.
  • Page 11 Parallel Interface PNP I/O type FJ-3005/FJ-3055/FJ-H3005/FJ-H3055 FJ-3005-10/FJ-3055-10/FJ-H3005-10/FJ-H3055-10 Internal Specifications [Input] signals: STEP0/ENCTRIG_Z0, STEP1/ENCTRIG_Z1, [Input] signals: RESET, DI0 to DI7, DSA0, DSA1 ENCTRIG_A0 to 1, ENCTRIG_B0 to 1 Input voltage 12 to 24 V DC ±10 % Input voltage 12 to 24 V DC ±10 % ON current *1 5 mA min.
  • Page 12: Serial Interface

    • Recommended items Use a shielded cable. Manufacturer Model Pin numbers will depend on the external device being connected. Refer Socket OMRON Corporation XM3D-0921 to the manual for the personal computer or PLC being connected. Hood OMRON Corporation XM2S-0913 LCD integrated type...
  • Page 13 Mounting LCD integrated type (Unit: mm) • Panel mounting 1 Make a mount hole on the panel. Panel thickness range: 1.6 to 4.8 mm Panel material: Metal (iron, aluminum or stainless) * No burr allowed 2 Insert the LCD integrated controller into the hole, from the front panel.
  • Page 14 Controller External Dimensions LCD integrated type FJ-3000/FJ-3005/FJ-H3000/FJ-H3005 (Unit: mm) 4-M3 Depth 6 12.8 28.4 – Box type FJ-3050/FJ-3055/FJ-H3050/FJ-H3055 (Unit: mm) 4-M4 Depth 6 4-M4 Depth 6 – 11.5 4-M4 Depth 6...
  • Page 15 Controller External Dimensions LCD integrated type FJ-3000-10/FJ-3005-10/FJ-H3000-10/FJ-H3005-10 (Unit: mm) 4-M3 Depth 6 12.8 28.4 Box type FJ-3050-10/FJ-3055-10/FJ-H3050-10/FJ-H3055-10 (Unit: mm) 4-M4 Depth 6 4-M4 Depth 6 – 11.5 4-M4 Depth 6...
  • Page 16: Controller Specifications

    Controller Specifications Operation LCD integrated type: Touch pen, mouse etc. BOX type: Mouse or similar device Serial communications RS-232C/422: 1 channel Network communications Ethernet 100BASE-TX/10BASE-T EtherNet/IP communication Use Ethernet port. Transmission speed: 100Mbps (100BASE-TX) Parallel I/O 17 inputs (RESET, STEP0/ENCTRIG_Z0, STEP1/ENCTRIG_Z1, DSA0 to 1, ENCTRIG_A0 to 1, ENCTRIG_B0 to 1, DI0 to 7) 29 outputs (RUN/BUSY1, BUSY0, GATE0 to 1, OR0 to 1, READY0 to 1, ERROR, STGOUT0 to 3, DO0 to 15)
