  • Page 1 Braukmann V5004TF Installation instructions Einbauanleitung Kombi-QM Pressure Independent Balancing and Control Valve Kombi-QM Druckunabhängiges Strangregulier- und Regelventil...
  • Page 2: Table Of Contents

    Actuator's features ..3 Installation Instructions . 3 External Interface ..5 Control Method ..7 Initial Setting ..7 Ratio of Value of Flow According to Flow Curve10 Manual Override...
  • Page 3: Actuator's Features

    Actuator's features Installation Instructions • Proportional control Mount the valve with the arrow in the direction of the • analogue (voltage and current), PWM, 3 points and flow ON/OFF CAUTION! • Position detecting Mounting it in the wrong direction may damage the •...
  • Page 4 Through additional battery Note: no condensation 2.1.4 Installation If the actuator M5004 is purchased with the valve Resideo Maintenance and Cleaning V5004TF, it is already installed onto the valve. If it is bought as a spare part, follow the next procedure: Use a damp cloth to clean the actuator.
  • Page 5: External Interface

    (SET 4); if it is bought as spare SET6 Rotation angle compensation part, the customer must inform Resideo about valve type the SET7 Flow offset compensation actuator will be mounted on, allowing Resideo's technicians...
  • Page 6 3.2 Actuator Wiring Guide Number Input Remarks Colour Black White Green Blue Feedback: Power: cable 1 - 2 Internal control Common 24 AC/DC 0(2) - 10 V 0(4) - 20 mA Power: cable 1 - 2 Feedback: 0 - 10 V DC Voltage signal Common 24 AC/DC 0(2) - 10 V...
  • Page 7: Control Method

    Control Method Internal control* ON/OFF Voltage signal 3 points signal Current signal PWM signal PWM Type 1: 0.1 - 5 s/Step 20ms PWM Type 2: 0.1 - 25 s/Step 100ms Note: * Flow rate can be set by buttons on the actuator and read on the 4 digits display. Initial Setting Power on display indicates ’Go-0’...
  • Page 8 SET2 Voltage control signal Control with voltage signal Voltage control signal Control with voltage signal Current control signal Control with current signal Current control signal Control with current signal On/Off 24V: open. 0V: close 3 Point Floating Input 24 V open if white wire connected (3) 24 V close if green wire connected (4) Remote control Not available...
  • Page 9 SET8 Valve open at power failure Selection Fail-CLOSE or Fail-OPEN option. Additional battery needed. Available with VA5004TF0001 Valve close at power failure SET9 Unit of SI (m Select with up/down buttons and then press “MODE“ to confirm Unit of GPM (gal/min) SET10 Linear control curve Select with up/down buttons and then press “MODE“...
  • Page 10: Ratio Of Value Of Flow According To Flow Curve10

    5.2 Setting parameter SET 4: PRESETTING Valve V5004T V5004T V5004T V5004T V5004T V5004T V5004TF V5004TF V5004TF V5004TF F1050 F1065 F1080 F1100 F1125 F1150 1200LF 1200HF 1250LF 1250HF presetting flow rate presetting flow rate The presetting flow rate of valve V5004TF can be set through the parameter SET 4 of the M5004 actuator: the parameter should set between the max and min presetting flow rate of the valve.
  • Page 11: General

    General 7.2 Valve-Actuator Assembly Resideo does not accept any liability for improper or wrong use of this product. Always protect the pressure regulator by using strainers upstream of the valve and, in any case, make sure water quality complies with VDI 2035 standards (Fe < 0.5 mg/kg and Cu <...
  • Page 12: Funktionsmerkmale Des Stellantriebs

    Funktionsmerkmale des Einbauanleitung Stellantriebs Montieren Sie das Ventil mit dem Pfeil in • Proportionale Regelung Durchflussrichtung. • analog (Spannung und Strom), PWM, 3 Punkte und VORSICHT! EIN/AUS Durch eine falsche Montage können das System • Positionserkennung und das Ventil selbst beschädigt werden. •...
  • Page 13 Verwenden Sie keine Reinigungsmittel oder 2.1.4 Montage chemischen Produkte, da sie die Funktion des Ventils Wenn der Stellantrieb M5004 mit dem Ventil Resideo beeinträchtigen oder das Ventil beschädigen können. V5004TF gekauft wird, ist er bereits auf dem Ventil montiert. Wenn er als Ersatzteil gekauft wird, befolgen Sie die nächste 2.1 M5004...
  • Page 14 Antriebsdrehzahl Kunde den Ventiltyp angeben, an dem der Stellantrieb SET14 Auswahl Rückmeldesignal montiert werden soll, damit ihn die Techniker von Resideo richtig einstellen können. 2.1.6 Entnahme Wenn der Stellantrieb mit Strom versorgt wird, wird der Wenn der Stellantrieb demontiert werden muss, befolgen Sie entsprechende Code des Ventils V5004TF auf dem die nächste Verfahrensanweisung:...
  • Page 15: Externe Schnittstelle

    Externe Schnittstelle 3.1 Kabelbezeichnung Schwarz Masse 24VAC/DC Weiß Steuerungssignal 1 Grün Steuerungssignal 2 Blau Rückmeldung 3.2 Verkabelung des Stellantriebs Numme Eingan Anmerkungen gswert Farbe schwarz weiß grün blau Rückmeldung: Spg. Versorg.: Kabel 1 - 2 gemein- interne Kontrolle 24 AC/DC 0(2) - 10 V 0(4) - 20 mA Spg.
  • Page 16: Regelmethode

    Regelmethode interne Kontrolle* Auf/Zu MASSE MASSE OFFEN: 24 VDC 24 VAC/24VDC GESCHLOSSEN: 0 VDC 24 VAC/24VDC Spannungssignal 3-Punkt-Signal MASSE RÜCKMELDUNG 24 VAC/24VDC SCHLIEßUNG MASSE 0(2)-10 V ÖFFNUNG 24 VAC/24VDC 0(4)-20 mA 24 VAC/24VDC 0-10 VDC 24 VAC/24VDC 2-10 VDC aktuelles Signal PWM Signal RÜCKMELDUNG MASSE...
  • Page 17 SET2 Spannungsreglungssignal Regelung mit Spannungssignal Spannungsreglungssignal Regelung mit Spannungssignal Stromregelungssignal Regelung mit Stromsignal Stromregelungssignal Regelung mit Stromsignal Ein/Aus 24V: offen. 0V: geschlossen 3-Punkt-Eingang 24 V offen, wenn weißer Draht angeschlossen ist (3); 24 V geschlossen, wenn grüner Draht angeschlossen ist (4) Fernsteuerung Nicht verfügbar PWM 5 Sek...
  • Page 18 SET8 Ventil bei Stromausfall offen Ausfall-OFFEN oder Ausfall-GESCHLOSSEN Modus anwählen. Eine zusätzliche Batterie wird benötigt Verfügbar mit VA5004TF0001 Ventil bei Stromausfall geschlossen SET9 SI-Einheit (m Auswählen mit der Nach-oben-/Nach-unten-Taste und Festlegen mit der Modustaste GPM-Einheit (gal/min) SET10 Lineare Kennlinie Auswählen mit der Nach-oben-/Nach-unten-Taste und Festlegen mit der Modustaste gleich gleichprozentige Kennlinie SET11*...
  • Page 19: Verhältnis Des Volumenstromwerts Gemäß Volumenstromkennlinie

    5.2 Einstellung Parameter SET 4: VOREINSTELLUNG Ventil V5004 V5004 V5004 V5004 V5004 V5004 V5004TF V5004TF V5004TF V5004TF TF1050 TF1065 TF1080 TF1100 TF1125 TF1150 1200LF 1200HF 1250LF 1250HF Max. Vorein- stellungs- volumenstrom Min. Vorein- stellungs- volumenstrom Der Voreinstellungs-Volumenstrom von Ventil V5004TF kann über den Parameter SET 4 des Stellantriebs M5004 eingestellt werden: Der Parameter sollte zwischen dem maximalen und minimalen Voreinstellungs-Volumenstrom des Ventils liegen.
  • Page 20: Allgemeines

    Allgemeines 7.2 Ventil-Stellantrieb-Baugruppe Resideo lehnt jegliche Haftung für die unsachgemäße oder fehlerhafte Nutzung diese Produkts ab. Vor dem Ventil ist in der Versorgungsleitung ein Schmutzfänger vorzusehen und es muss immer sichergestellt werden, dass die Wasserqualität dem VDI 2035-Standard entspricht (Fe < 0,5 mg/kg und Cu < 0,1 mg/ kg).
  • Page 21 MU1H-2327GE23 R0520...
  • Page 22 Pittway Sàrl, Z.A., La Pièce 4, Ademco 1 GmbH, Hardhofweg 40, 1180 Rolle, Switzerland 74821 MOSBACH, GERMANY by its authorised representative Phone: +49 6261 810 Ademco 1 GmbH Fax: +49 6261 81309 © 2020 Resideo Technologies, Inc. All rights reserved. Subject to change. MU1H-2327GE23 R0520...
