Bom; I2C-Usb Bridge Bom Rev. E - Cypress I2C-USB Manual

A.3

BOM

A.3.1

I2C-USB Bridge BOM Rev. E

Item Qty Reference
1 1 C1
2 1 C2
3 1 C3
4 1 C4
5 2 C5, C6
6 1 R1
7 1 R2
8 1 R3
9 1 R4
10 1 R5
11 1 R6
12 1 R7
13 1 R8
14 2 R9, R10
15 2 R11, R12
16 1 R13
17 2 R14, R15
18 2 R16, R17
R18, R19,
19 3
R20
20 1 J1
21 1 J2
22 1 J3
23 1 J4
24 2 F1, F2
25 1 D1 *
26 1 D2 *
27 2 D3, D4
28 1 U1
29 1 U2
30 1 U4 *
31 1 U5
32 1 U6
33 2 * 000
34 1 * 000
35 1 J1 *
44
Description
PCB
CAP CER .10UF 25V X7R 10% 0805
CAP CER 1.0UF 10V 10% X7R 0805
CAP CER 2.2UF 16V Y5V 1206
CAP CER 10000PF 50V 10% X7R 1206
CAP CERAMIC .01UF 100V X7R 0603
RES 52.3K OHM 1/10W 1% 0603 SMD
RES 5.1K OHM 1/10W 5% 0603 SMD
RES 24.0K OHM 1/10W 1% 0603 SMD
RES 6.8K OHM 1/10W 5% 0603 SMD
RES 51K OHM 1/8W 5% 0805 SMD
RES 10K OHM 1/10W 5% 0603 SMD
RES 30.1K OHM 1/10W 1% 0603 SMD
RES 51K OHM 1/10W 5% 0603 SMD
RES 22 OHM 1/8W 5% 0805 SMD
RES 300 OHM 1/10W 5% 0603 SMD
RES 100K OHM 1/10W 5% 0603 SMD
RES 7.5K OHM 1/10W 5% 0603 SMD
RES 30K OHM 1/10W 5% 0603 SMD
RES 47 OHM 1/10W 5% 0603 SMD
CONN HEADER VERT 2POS .100 TIN
CONN HEADER VERT 5POS .100 TIN
CONN HEADER .100 SNGL STR 5POS
CONN USB RCPT MINI-B 5POS RT ANG
POLYSWITCH 1.10A RESET FUSE SMD
LED 660NM RED WTR CLR 1206 SMD
LED 565NM WTR CLR GREEN 1206 SMD
Supressor 5V SMB package
IC LDO REG 1A SOT223-6 TPS73701
CY8C24894
IC Single USB Port TVS SOT-23-6
IC LVL XLTR LV 8MBPS 14-TSSOP
TVS Array ESD 6 Input 8-SOIC
RES 0.0 OHM 1/8W 5% 0805 SMD
RES 0.0 OHM 1/8W 5% 0603 SMD
Shunt
CY3240-I2USB I2C-USB Bridge Guide, Doc. # 001-66660 Rev.**
Manufacturer Mfr Part Number
Cypress Semiconductor PDC-9334
TDK C2012X7R1E104K
Murata Electronics North
GRM21BR71A105KA01L
America
Murata GRM31MF51C225ZA01L
Murata GRM319R71H103KA01D
Kemet C0603C103K1RACTU
Yageo RC0603FR-0752K3L
Yageo RC0603JR-075K1L
Yageo RC0603FR-0724KL
Yageo RC0603JR-076K8L
Yageo RC0805JR-0751KL
Yageo RC0603JR-0710KL
Yageo RC0603FR-0730K1L
Yageo RC0603JR-0751KL
Panasonic - ECG ERJ-6GEYJ220V
Yageo RC0603JR-07300RL
Rohm MCR03EZPJ104
Yageo RC0603JR-077K5L
Yageo RC0603JR-0730KL
Yageo RC0603JR-0747RL
Molex/Waldom Electronics
22-28-4020
Corp
Molex/Waldom Electronics
22-28-4050
Corp
3M Electronics 929850-01-05-10
Delphi Connection Sys-
15430262-110
tems
Tyco Electronics/Ray-
MINISMDC110-2
chem Circuit Protection
Lumex Opto/Components
SML-LX1206SRC-TR
Inc
Lumex Opto/Components
SML-LX1206GC-TR
Inc
Littelfuse Inc SMBJ5.0CA
Texas Instruments TPS73701DCQ
Cypress Semiconductor CY8C24894-24LFXI
Texas Instruments SN65220DBVT
Maxim MAX3378EEUD+
Littelfuse Inc SP721ABG
Rohm MCR10EZHJ000
Rohm MCR03EZPJ000
3M 929950-00
