Summary of Contents for PCE Instruments PCE-WO2 10
- Page 1 User Manual PCE-WO2 10 Oxygen Meter User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Last change: 8 August 2019 v1.0 © PCE Instruments...
-
Page 2: Table Of Contents
16 Dissolved Oxygen Measurement ............11 17 Auto-Hold ..................... 11 18 Electrode Care and Maintenance ............12 19 Troubleshooting .................. 12 20 Addendum: Preparation of the Zero Oxygen Solution ....12 21 Warranty ....................13 22 Disposal ....................13 © PCE Instruments... -
Page 3: Safety Notes
We expressly point to our general guarantee terms which can be found in our general terms of business. If you have any questions please contact PCE Instruments. The contact details can be found at the end of this manual. © PCE Instruments... -
Page 4: Technical Specifications
175 x 40 mm / 6.8 x 1.5" Weight 100 g / 3.5 oz Delivery Scope 1 x Dissolved Oxygen Meter PCE-WO2 10 1 x Oxygen probe with measuring cable 2 x Membrane 1 x Electrolyte solution (30ml) 2 x 1.5 V AAA batteries... -
Page 5: Installing The Batteries
Twist the electrode collar clockwise until it is tight. Display PCE-WO2 10 pocket dissolved oxygen tester is equipped with an easy-to-read LCD display that used to show the measured values and mode icons. The following table describes the function of each icon. -
Page 6: Keypad
• Press the key to start the calibration. • Press and hold the key to enter the setup menu. • In the setting mode, press the key to select the default option. • Confirms the calibration or selected option. ENTER © PCE Instruments... -
Page 7: Filling The Electrolyte Solution
Connecting the Dissolved Oxygen Probe Insert the 6-pin connector of probe into the connector socket on the tester. After the connection is completed, DO NOT pull on the cable. Always make sure that the connector is clean and dry. © PCE Instruments... -
Page 8: Switching The Tester On And Off
Switch on the tester 10 to 15 minutes and wait for the probe to polarize. Setup Menu PCE-WO2 10 pocket dissolved oxygen tester contains an integrated setup menu that is used to customize the displayed option to meet measurement requirements. -
Page 9: Setting The Default Option
Enter or °F/CAL option. • The Reset function will restore the tester back to factory default settings. If enabled, all of the calibration data and selected parameters will be lost or reset, the tester must be recalibrated. © PCE Instruments... -
Page 10: Setting The Salinity Coefficient
• Press the key to set the value. • Press the key to confirm, the display shows the next menu item. Enter • Press the key to exit the setting and return to the measurement mode. Meas © PCE Instruments... -
Page 11: Do Calibration In % Saturation Mode
DO Calibration in % Saturation Mode PCE-WO2 10 pocket dissolved oxygen tester can be calibrated quickly in air. In the percentage saturation mode, the tester is able to perform either 1 or 2 points calibration. For single point calibration, we recommend that you perform 100% saturation calibration in the air-saturated water. -
Page 12: Temperature Calibration
Press the key again to modify the temperature value (Resolution: 0.5°C). • Press the Enter key to confirm, the tester shows the next menu item. • Press the key to return to the Meas measurement mode. Calibration completed. © PCE Instruments... -
Page 13: Dissolved Oxygen Measurement
Dissolved Oxygen Measurement PCE-WO2 10 pocket dissolved oxygen tester is suitable for measuring the water, wastewater, brine and other liquids. If the sample is belong to the seawater or other water containing large amounts of salt, please setting the salinity coefficient before measurement. Some gas and steam... -
Page 14: Electrode Care And Maintenance
Addendum: Preparation of the Zero Oxygen Solution Dissolve 500mg of sodium sulfate (Na ) reagent and a small amount of cobalt (II) chloride • 6H hexahydrate (CoCl O) in the 250mL distilled water, mix the solution until the reagent is completely dissolved. © PCE Instruments... -
Page 15: Warranty
For countries outside the EU, batteries and devices should be disposed of in accordance with your local waste regulations. If you have any questions, please contact PCE Instruments. © PCE Instruments... - Page 16 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 4 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 Soultz-Sous-Forets 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17...
