Federal Signal Corporation SIGNALMASTER SMLED2F Instruction Sheet

2561601C
REV. C 602
Printed in U.S.A.
SAFETY MESSAGE TO INSTALLERS
People's lives depend on your safe installation of
our products. It is important to read, understand and
follow all instructions shipped with the products. In
addition, listed below are some other important
safety instructions and precautions you should
follow:
• To properly install this light: you must
have a good understanding of automotive
electrical procedures and systems, along
with proficiency in the installation and
use of safety warning equipment.
• When drilling into a vehicle structure, be
sure that both sides of the surface are
clear of anything that could be damaged.
• In order for the light to function properly,
a separate ground connection must be
made. If practical, it should be connected
to the negative battery terminal. At a
minimum, it may be attached to a solid
metal body or chassis part that will
provide an effective ground path as long
as the light system is to be used.
• Locate light control so the VEHICLE and
CONTROL can be operated safely under
all driving conditions.
• Do not attempt to activate or deactivate
light control while driving in a hazardous
situation.
• This product contains high intensity LED
devices. To prevent eye damage, DO NOT
stare into the light beam at close range.
• You should frequently inspect the light to
ensure that it is operating properly and
that it is securely attached to the vehicle.
• File these instructions in a safe place and
refer to them when maintaining and/or
reinstalling the product.
Failure to follow all safety precautions and
instructions may result in property damage, serious
injury, or death to you or others.
A. GENERAL.
Federal SignalMaster™ Model SMLED2F is an
economical, low wattage, directional light designed
INSTRUCTION SHEET
FOR
SIGNALMASTER™ MODELS SMLED2F
for use in a flashing mode. Each unit is supplied with
a mounting bracket, adhesive pads, and velcro strips
which allow flexible mounting arrangements. Lens
colors (amber, red, blue, or clear) are specified when
ordering. The lenses are interchangeable, and can be
ordered separately.
B. UNPACKING.
After unpacking the light, inspect it for damage
that may have occurred in transit. If the unit has
been damaged, do not attempt to install or operate it.
File a claim immediately with the carrier, stating the
extent of damage. Carefully check all envelopes,
shipping labels, and tags before removing or destroy-
ing them. Ensure that the parts listed in the appro-
priate KIT CONTENTS LIST are included in the
package.
C. KIT CONTENTS LIST.
Qty. Description
2 Screw, Hex Hd., 1/4 x 1/2
3 Screw, Hex Hd., 1/4 x 5/8
2 Lockwasher
1 Velcro, Hook
1 Velcro, Loop
1 Adhesive Pad
1 Bracket, Bail
These lights are intended for secondary
warning only. They are not intended for use
as a primary warning system.
D. INSTALLATION.
When installing equipment inside air bag
equipped vehicles, the installer MUST ensure
that the equipment is installed ONLY in
areas recommended by the vehicle manufac-
turer.
Failure to observe this warning will reduce
the effectiveness of the air bag, damage the
air bag, or potentially damage or dislodge the
equipment, causing serious injury or death to
you or others.
Part No.
7011164-08
7011165-10
7075078
8550A101
8550A100
8550A031
8573118
WARNING
WARNING
