Mocka Harlin Kids Cabinet Assembly Instructions Manual

Harlin Kids Cabinet
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
A B C D
bolt locking dowel long
x30 nut x30 x20 screw x4
G H I
hinge L + R slide L + R slide
x2 rail x6 rail x6
Phillips & Flathead screwdrivers
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
*We recommend using a Flathead screwdriver to tighten all locking nuts 100% before first use.
Please clear any loose wood from the locking nut holes before inserting the nut to ensure it locks 100%.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
E F
small medium safety
screw x24 screw x12 strap
x2
J K
shelf plug screw
wall
x4 x12
anchor
x2
WARNING: Any furniture that is not anchored to a wall has the potential to tip
W
over in certain circumstances, i.e. if a child attempts to climb up on the furniture
or in the event of an earthquake. Accordingly, we recommend that all furniture
is anchored to a wall. We supply a free safety wall anchor with all furniture sold
and we recommend these are used to prevent your product tipping. The fixing
device provided should fit most wall types, but please note that different wall
materials may require different fixing devices from those supplied.
long
screw
x2
X Y
screw
x2
Z
washer
x2
