Mocka Harlin Kids Bedside Table Assembly Instructions Manual

Harlin Kids Bedside Table
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
B
A
bolt locking dowel
x16 nut x16
E F
small long
screw x16 screw x8
Phillips & Flathead screwdrivers
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
*We recommend using a Flathead screwdriver to tighten all locking nuts 100% before first use.
Please clear any loose wood from the locking nut holes before inserting the nut to ensure it locks 100%.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
C
D
safety
L + R slide
x8 strap
rail x4
x1
G
L + R slide
wall
rail x4
anchor
x1
WARNING:
W
over in certain circumstances, i.e. if a child attempts to climb up on the furniture
or in the event of an earthquake. Accordingly, we recommend that all furniture
is anchored to a wall. We supply a free safety wall anchor with all furniture sold
and we recommend these are used to prevent your product tipping. The fixing
device provided should fit most wall types, but please note that different wall
materials may require different fixing devices from those supplied.
long
screw
x1
X Y
screw
x1
Z
washer
x1
Wall Strap
Any furniture that is not anchored to a wall has the potential to tip
1
