Azbil AUR450C User Manual

Azbil AUR450C User Manual

Dynamic self-checking burner controller
Hide thumbs
Table of Contents

Advertisement

Quick Links

No. CP-SP-1264E
Dynamic Self-Checking
Burner Controller
Model AUR450C
User's Manual
Thank you for purchasing an Azbil
Corporation product.
This manual contains information for
ensuring the correct use of this product.
It also provides necessary information
for installation, maintenance, and
troubleshooting.
This manual should be read by those who
design and maintain equipment that uses
this product. Be sure to keep this manual
nearby for handy reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AUR450C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Azbil AUR450C

Summary of Contents for Azbil AUR450C

  • Page 1 No. CP-SP-1264E Dynamic Self-Checking Burner Controller Model AUR450C User’s Manual Thank you for purchasing an Azbil Corporation product. This manual contains information for ensuring the correct use of this product. It also provides necessary information for installation, maintenance, and troubleshooting.
  • Page 2 If you should find an error or omission, please contact the azbil Group. In no event is Azbil Corporation liable to anyone for any indirect, special or consequential damages as a result of using this product. © 2007–2019 Azbil Corporation. All Rights Reserved.
  • Page 3 Conventions Used in This Manual „ The safety precautions explained in the following section aim to prevent injury to the operator and others, and to prevent property damage.   W ARNING Warnings are indicated when mishandling this product might result in death or serious injury.  ...

  • Page 4: Safety Precautions

    Safety Precautions WARNING This device does not have a prepurge function. Use this device as part of a system whose design gives careful consideration to the prepurge timer and ignition sequence timing, following established safety guidelines. Connect loads (ignition transformer, solenoid valve, etc.) directly to the output terminals of this device.
  • Page 5 WARNING When the pilot turndown test is complete, turn OFF the power switch to shut down the power. Restore all test jumpers and limit interlock/regulator settings to their previous states. If operation begins without the above steps, damage to the equipment, gas leak or explosion may result.
  • Page 6 CAUTION Make sure the load connected to each terminal does not exceed the rating indicated in the specifications. If timers and auxiliary relays are needed for additional functions, select ones with high reliability, and be sure to design the circuit correctly. When installing and wiring, be sure to follow the instructions in this manual and in the user's manual for the combustion equipment.
  • Page 7 CAUTION When cleaning the burner, clean the flame detector as well. For transportation or storage of this device, remove it from the subbase and pack it in its original box. It might be damaged if transported while mounted on a panel or the like. Do not short the control load terminals (18-19, 18-20, 18-21, or 18-22) or the shutter terminals (7-8).

  • Page 8: The Role Of This Manual

    The Role of This Manual A total of 8 different manuals are available for the AUR450C. Read them as necessary for your specific requirements. If a manual you require is not available, contact the azbil Group or its dealer. Dynamic Self-Checking Burner Controller Model AUR450C User’s Manual Manual No.
  • Page 9 Manual No. CP-UM-5942JE This manual is supplied with the subbase. Those who design or manufacture equip- ment that uses the AUR450C should read this manual thoroughly. The subbase is necessary when installing the AUR450C in a panel, etc. This manual describes in- stallation and wiring of the subbase.

  • Page 10: Organization Of This User's Manual

    Chapter 2. MOUNTING AND WIRING Installation, wiring and wiring check methods. Chapter 3. OPERATION Internal block diagram of the AUR450C and sequence charts showing its operation. Chapter 4. TRIAL-RUN ADJUSTMENT Adjustment of the AUR450C and tests that are necessary before operating it.

  • Page 11: Table Of Contents

    „ Connection to a 5-wire system 2-12 Chapter 3. OPERATION „ Example of instrumentation for the Model AUR450C with an interrupted pilot „ Precautions for instrumentation and circuit configuration with an interrupted pilot 3-1 „ Internal block diagram „ Sequence charts...
  • Page 12 „ Example of instrumentation for the Model AUR450C with an intermittent pilot 3-10 „ Precautions for instrumentation and circuit configuration with an intermittent pilot 3-10 „ Internal block diagram 3-11 Chapter 4. TRIAL-RUN ADJUSTMENT „ Outline of adjustment „ Preliminary inspection „...

  • Page 13: Chapter 1. Overview

    Chapter 1. OVERVIEW „ Overview The AUR450C Dynamic Self-Checking Burner Controller (hereafter the/this device) is a flame safeguard controller that safely and automatically ignites and monitors a gas or oil burner using the correct sequence of steps. It executes both...

  • Page 14: X84; System Structure

    Vibration Overtemperature limit detection limit Vibration Controller Air pressure lower limit detector interlock Limit/Interlock Exhaust Burner controller (AUR450C) Combustion chamber Flue duct Exhaust damper MV1 MV2 interlock PV1 PV2 Gas pressure lower limit interlock Combustion...

  • Page 15: X84; Precautions For Designing Equipment

    No. time compliance response time supply processing 1 processing 2 AUR450C Dynamic self-checking burner controller 4±1 s 8±2 s With standards compliance 1.5 s Nominal (2 s maximum) 3 s Nominal (4 s maximum) 100 V AC CE, UL, FM standards...

  • Page 16: X84; Related Devices

    Low Voltage Directive (2014/35/EU) Electromagnetic compatibility Directive (2014/30/EU) RoHS Directive (2011/65/EU) • FM: File No. 0003059531 Certificates are valid only for a combination of AUR450C, AUD300C, and Q241A104. „ Names and functions of parts z Controller DISP switch Switches between sequence code and ame voltage display.
  • Page 17 Chapter 1. OVERVIEW z LED display details Name Color Description POWER Green Lights up when the power is turned on EVENT Orange Lights up when an event occurs SHUTTER Green Lights up when the shutter is closed FLAME Green * Lights up when a flame is detected ALARM Lights up when there is an alarm...

  • Page 18: X84; Description Of 7-Segment Display

    Chapter 1. OVERVIEW „ Description of 7-segment display z Sequence code display Normally, a code is displayed corresponding to the present stage of the operation sequence. The table below shows the displayed code and the concurrent stage in the sequence. Display Sequence Description...
  • Page 19 EVENT LED light up and to have an event code displayed when an event occurs. For details how to event setup, refer to;  User’s manual for Smart Loader Package Model SLP-A45 for Dynamic Self-Checking Burner Controller Model AUR450C (CP-SP-1187E).

  • Page 20: X84; Terminal Block Signals

    Chapter 1. OVERVIEW „ Terminal block signals z Subbase terminal block The table below describes the terminals on the subbase. Terminal No. Description Rated Model AUD300C/500C terminal F (blue) Model AUD300C/500C terminal G (yellow) Unused Unused Unused Unused Model AUD300C/500C shutter (white) 24 V DC 150 mA Model AUD300C/500C shutter (white) External reset input...

  • Page 21: Chapter 2. Mounting And Wiring

    Before wiring, mounting, or removing this device, be sure to turn the power off. Wiring with the power on can result in an electric shock. CAUTION Do not mount the AUR450C in the following places: • In the presence of chemicals or corrosive gas, such as ammonia, sulfur, chlorine, ethylene compound, acid, or others.

  • Page 22: X84; Mounting Posture

    Incorrect Correct Front of controller Panel Panel Front of controller AUR450C Panel AC xxxV 50/60Hz XXXXX XXXXXX MADE IN JAPAN Front of controller „ Mounting the subbase Mount the subbase on a vertical surface. The threaded hole for the body-subbase screw should be in the lower portion of the vertically oriented subbase.

  • Page 23: X84; Mounting The Controller

    Chapter 2. MOUNTING AND WIRING „ Mounting the controller The method of mounting the controller on the subbase is described below. (1) With the controller positioned so that the main unit-subbase screw is near the bottom, latch the hook on top and then lower the controller so that it meets the subbase.

  • Page 24: Wiring

    Chapter 2. MOUNTING AND WIRING 2 - 2 Wiring WARNING Connect loads (ignition transformer, solenoid valve, etc.) directly to the output terminals of this device. Otherwise, combustion safety cannot be ensured. When using an auxiliary relay due to lack of contact capacity, etc., take protective measures in case a relay malfunction or contact welding occurs.

  • Page 25: X84; Wiring Diagram

    Failure to observe this warning could lead to an explosion. Power supply Start contact Interlock input input Flame monitor output Subbase for AUR450C Note Wiring for input to terminals 15 and 18 through (H) contacts, without using terminals 16 and 17, is also possible. Start Interlock Shut- Unused contact...
  • Page 26 Connecting to a surge absorber When using the optional surge absorber as a protective measure against lightning, connect it as shown below. Model No.: 83968019-001 (sold separately) AUR450C AUR450C ～ ～ Power supply Power supply...

  • Page 27: X84; Connection To The Model Aud300C/500C

    Chapter 2. MOUNTING AND WIRING „ Connection to the Model AUD300C/500C Wire the AUD300C/500C as shown below. AUD300C/500C AUR450C • • • • • Blue (F) White White Yellow (G) Handling Precautions • The signal wires of the AUD300C/500C (blue and yellow) have specific polari- ties.

  • Page 28: X84; Wiring To A Solenoid Valve

    This device will not be able to prevent the valve from opening and fuel from flowing out. z Correct connection AUR450C High potential side (H) Power supply Low potential side (G)

  • Page 29: X84; Wiring For Continuous Measurement Of Flame Voltage

    Chapter 2. MOUNTING AND WIRING „ Wiring for continuous measurement of flame voltage To measure the flame voltage, remove the cover from the flame voltage terminal and connect a signal wire to it. Handling Precautions • Always use an IV cable with a size of 0.75 mm or more for signal lines.
  • Page 30 Chapter 2. MOUNTING AND WIRING z Mounting the terminal cover When wiring is done, reattach the flame voltage terminal cover. (1) Insert the left part of the cover into the square hole on the controller. (2) Push the right side of the cover into place by hand. 2-10...

  • Page 31: Communications Connections

    For details operations of SLP, refer to; User’s manual for Smart Loader Package Model SLP-A45 for Dynamic Self- Checking Burner Controller Model AUR450C (No. CP-SP- 1187E). „ Connection of RS-485 communications For RS-485 communications, remove the cover from the RS-485 communications connector and attach a compatible connector The controller uses 3-wire RS-485 communications.

  • Page 32: X84; Connection To A 3-Wire System

    Chapter 2. MOUNTING AND WIRING „ Connection to a 3-wire system AUR450C 3-wire system AUR450C AUR450C „ Connection to a 5-wire system AUR450C 5-wire system AUR450C AUR450C IMPORTANT Terminating resistor • Do not connect any terminating resistor to either end of the communication path.

  • Page 33: Chapter 3. Operation

    Chapter 3. OPERATION „ Example of instrumentation for the Model AUR450C with an interrupted pilot Overtemperature limit Vibration detection limit Controller Vibration Air pressure lower limit detector Limit/Interlock interlock Exhaust Burner controller (AUR450C) Combustion chamber Flue duct Exhaust damper MV1 MV2...

  • Page 34: X84; Internal Block Diagram

    Vibration Gas pressure lower Overtemperature detection limit interlock limit limit Air pressure lower (Interlock/ Gas pressure upper limit interlock Limit contacts) limit interlock AUR450C Power supply circuit Interlock Blue Prepurge input circuit Flame amplifying Yellow Fuse circuit Burner start contacts...

  • Page 35: X84; Sequence Charts

    Sequence charts include the following operations. When the blower on-off circuit and prepurge circuit completes the prepurge, the prepurge completion contacts connected to terminal 18 of the AUR450C are turned ON, the burner start contacts are turned ON, and burner operation proceeds.
  • Page 36 Chapter 3. OPERATION z Start check error due to false flame If an error (false flame) is detected during the start check and normal operation does not resume for 10 seconds, the system is locked out. While the false flame is detected, the K6 flame monitor output is ON.
  • Page 37 Chapter 3. OPERATION z Start check error due to self-discharge If an error (self-discharge) is detected during the start check and normal operation does not resume for 10 seconds, the system is locked out. In this case, there is no flame monitor output and the FLAME LED does not light up.
  • Page 38 Chapter 3. OPERATION z Ignition failure If ignition is not detected after the ignition trial time period, the system is locked out and an alarm is output. On the device, E4 (ignition failure) and P2 are displayed alternately. Standby Pre-purge Start Ignition trial Lockout...
  • Page 39 Chapter 3. OPERATION z Flame failure If a flame failure is detected during Run, the system is locked out and an alarm is output. On the device, E5 (flame failure) and P5 are displayed alternately. Standby Pre-purge Start Ignition trial Pilot Stabilization Main trial Flame...
  • Page 40 Chapter 3. OPERATION z Interlock during Run-state If the interlock contact is disconnected or changed to OFF, the system is locked out and an alarm is output. On the device, E1 (interlock) and P5 are displayed alternately. Standby Pre-purge Start Ignition trial Pilot Stabilization Main trial...
  • Page 41 Chapter 3. OPERATION z Interlock during stand-by state The system is not locked out though the interlock contact is disconnected or changed to OFF during standby, and then a start signal is input, the system is locked out and an alarm is output. On the device, E1 (interlock) and P1 are displayed alternately.

  • Page 42: X84; Example Of Instrumentation For The Model Aur450C With An Intermittent Pilot

    Chapter 3. OPERATION „ Example of instrumentation for the Model AUR450C with an intermittent pilot Vibration Overtemperature limit detection limit Limit/Interlock Controller Vibration Air pressure lower limit B.C. (AUR450C) detector interlock for pilot burner Exhaust B.C. (AUR450C) UV ame for main burner...

  • Page 43: X84; Internal Block Diagram

    Overtemperature Vibration detection limit interlock limit limit Air pressure lower (Interlock/ Gas pressure upper limit interlock Limit contacts) limit interlock AUR450C (for intermittent pilot burner) Power supply circuit Interlock Prepurge Blue input circuit Flame amplifying Yellow Fuse circuit Burner start...
  • Page 44 *2. When configuring the circuit, use the pilot ignition signal output as the condition for starting the burner controller for the main burner and for activating the interlock. *3. Be sure to set up a separate external reset input for each AUR450C. The external reset input of another AUR450C cannot be shared.

  • Page 45: Chapter 4. Trial-Run Adjustment

    Chapter 4. TRIAL-RUN ADJUSTMENT WARNING Do not allow the pilot or main burner “Safety time” (ignition trial time) to exceed the specifications of the burner or equipment manufacturer. If they do, fuel may accumulate in the combustion chamber and form an explosive airfuel mixture, resulting in a serious explosion hazard. Terminals and the connected flame detector signal cable retain an electrical charge even after the power is turned OFF.

  • Page 46: X84; Preliminary Inspection

    Chapter 4. TRIAL-RUN ADJUSTMENT „ Preliminary inspection (1) Inspect all wiring parts. (2) Check that the device is mounted in a place where the ambient temperature is within its allowable range. (3) Check that the AUD300C/500C is mounted correctly. In particular, be sure the blue lead wire (to terminal 1) and yellow lead wire (to terminal 2) of the AUD300C/500C are connected correctly.

  • Page 47: X84; Pilot Turndown Test

    Chapter 4. TRIAL-RUN ADJUSTMENT „ Pilot turndown test This test is intended to check that the flame is reliably transferred to the main burner when the AUD300C/500C detects a pilot flame if the gas pressure and air pressure change to their worst conditions. WARNING Carry out the pilot turndown test carefully.
  • Page 48 Chapter 4. TRIAL-RUN ADJUSTMENT (5) Close the manual valve for the pilot burner slowly. The pilot flame gradually becomes smaller. Gradually close the valve until the AUD300C/500C cannot detect the flame. (6) FLAME LED goes out, and the system is locked out. Record the gas pressure just before the lockout.

  • Page 49: X84; Ignition Spark Response Test

    Chapter 4. TRIAL-RUN ADJUSTMENT „ Ignition spark response test WARNING Make sure that the AUD300C/500C does not detect ultraviolet rays other than those of the burner. If the AUD300C/500C responds to other ultraviolet rays, flame failure in the burner will not be detected.

  • Page 50: X84; Safety Shutoff Test

    Chapter 4. TRIAL-RUN ADJUSTMENT „ Safety shutoff test After all operational adjustments have been completed, carry out the safety shutoff test. z Pilot ignition failure (ignition failure) (1) Close the pilot and main manual fuel valves. (2) Press the start switch. >>Operation begins.

  • Page 51: Chapter 5. Maintenance And Inspection

    Chapter 5. MAINTENANCE AND INSPECTION WARNING Before wiring, mounting, or removing this device, be sure to turn the power off. Wiring with the power on can result in an electric shock. Terminals and the connected flame detector signal cable retain an electrical charge even after the power is turned OFF.

  • Page 52: X84; Alarm Code And Description

    Chapter 5. MAINTENANCE AND INSPECTION „ Alarm code and description When lockout occurs an alarm code is automatically displayed. When the alarm is activated, the lockout sequence code and the alarm code are displayed alternately. Display Alarm name Description Start check alarm The start check was not completed for some reason such as momentary power failure or part malfunction.

  • Page 53: X84; Fault Inspection Flowchart

    Chapter 5. MAINTENANCE AND INSPECTION „ Fault inspection flowchart WARNING Before wiring, mounting, or removing this device, be sure to turn the power off. Wiring with the power on can result in an electric shock. When there is a problem with the equipment, follow the following inspection procedure: Turn the start switch OFF, and press the reset switch...
  • Page 54 Chapter 5. MAINTENANCE AND INSPECTION Use this sheet when checking controller status for inspection or troubleshooting Flame Detector and Burner Controller Status Checklist Date: Yr. __ Mo. __ Day __ Ckd by : ___________ Fill in the blanks and check the applicable boxes. End user name/equipment maker name: Equipment name/production line name or number:...

  • Page 55: Chapter 6. Specifications

    CE: Gas Appliance Directive (2009/142/EC) 0063BS1427 * Low Voltage Directive (2014/35/EU) Electromagnetic compatibility Directive (2014/30/EU) RoHS Directive (2011/65/EU) FM: File No. 0003059531 *1. Certificates are valid only for a combination of AUR450C, AUD300C, and Q241A104. *2. from 21st April 2018 GAR 2016/426...
  • Page 56 Allowable voltage range 85 to 110 % of power supply voltage Power consumption 15 W max. (including both AUR450C and AUD300C/500C) Dielectric strength 1500 V AC, 50/60 Hz for 1 min, between ground and primary terminals 11 to 24, or 1800 V AC, 50/60 Hz for 1 s.

  • Page 57: X84; External Dimensions

    Chapter 6. SPECIFICATIONS „ External dimensions Unit: mm AUR450C **** 000 AC xxxV 50/60Hz XXXXX XXXXXX MADE IN JAPAN 163 (Space required for dismounting the main unit) (31) DYNAMIC SELF CHECK BURNER CONTROLLER POWER AUR450 EVENT SHUTTER FLAME DISP ALARM...
  • Page 58 Memo...
  • Page 59 Revision History (CP-SP-1264E) Printed Edn. Revised pages Description June 2007 Jan. 2010 Overall revision May 2010 Delete Manual No. CP-SP-1170E and CP-SP-1211E. Delete AUR400C. Overview explanation changed. Model selection table conditions added. Figure changed. 3-7, 3-8 Graph corrected. Explanation changed. General specifications explanation added.

  • Page 60: Terms And Conditions

    Azbil Corporation's products shall be warranted for one (1) year from the date of your purchase of the said products or Azbil Corporation’s products shall be warranted for one (1) year from the date of your purchase of the said products or the delivery of the the delivery of the said products to a place designated by you.
  • Page 61 Although acceleration of the above situation varies depending on the conditions or environment of use of the products, you are required not to use any Azbil Corporation’s products for a period exceeding ten (10) years unless otherwise stated in specifications or instruction manuals.
  • Page 62 Specifications are subject to change without notice. (11) 1-12-2 Kawana, Fujisawa Kanagawa 251-8522 Japan https://www.azbil.com 1st edition: June 2007 (W) 8th edition: Sep. 2019 (V)
