Proteco Q60S Manual

Q60S/R Q60S

EXTERNAL RADIO PANEL

CONTROL UNIT

FOR SLIDING GATES
230V
EXTERNAL
RADIO
Q60S
PANEL 8.8.
A
B
DISPLAY
C
SI
+
D
NO _
1 2 3 4 5 6
Morsettiera 2
RESTORABLE FUSE 24V
IMPORTANT: If a temporary short circuit occurs the fuse will
restore itself after few seconds.
CODE FUNCTIONS
Show stored codes
New remote control
code acquisition
P C
Remote control code
acquisition with
STOP function
P
Remote control code
acquisition with
PEDESTRIAN function
C
Delete ALL remote
control codes
THE RADIO PANEL CAN ALSO BE PLACED
INSIDE THE BLINKER TO FURTHER IMPROVE
THE RADIO RANGE
Transformer
230V / 23V
Aerial
230V
V1
L
F3
CN
24V
Z2
V2
K1
AC
AC
K2
K3
F1
B
F2 F2
7 8 9 10 11 12
13 14 15 A 19
Morsettiera 3 Morsettiera 4
In case of a permanent short circuit, cut the main power
off, remove the terminal blocks 2A and 2B, wait few
seconds and then power the unit again.
The fuse will be automatically restored.
Find and remove the short circuit cause before plugging
the terminal blocks in.
— —
STAND BY
P A

PARAMETERS

A
RADIO
DEFAULT
A S
SEQUENTIAL
PROGRAMMING
CODE FUNCTIONS
I
Only
1 Motore

CONTROL UNIT COMPONENTS

A top level menu button
B lower level menu button
C button to increase or change to yes (si)
D button to decrease or change to no
F1 230V fuse 5A
F2 24V fuse (restorable) 0,6A
F3 24V fuse (restorable) 1,6A
DISPLAY 7 SEGMENTS Display
M1 radio/aerial terminal block
M2A/M2B Controls and safety devices terminal
blocks
N
M3 motor terminal block
M4 main power terminal block
A B
earth connections
A B
MR radio unit
CN not used connector
Z2 filter
K1/ K2 motor relay
K3 blinker relay
VI Primary Varistor
V2 Secondary Varistor
BUTTON A
Cycle round the top
level menu
20
BUTTON B
Move from the top
level menu to the lower
level menu
BUTTON C
Increase time
or change to YES
BUTTON D
Decrease time
or change to NO
CODE
I F
F
CODE FUNCTIONS
P
P
Press & hold button C
to set defaults
F
Tel. +39 0173 210111 - Fax +39 0173 210199
B use button B to move to next parameter
C use button C to INCREASE a numeric value or change NO to YES
D use button D to DECREASE a numeric value or change YES to NO
To save changes and to ensure that they are not lost when power is
removed, use button B to step through
button C until the display reverts to idle display .
8.8.
A
B
DISPLAY
C
SI
+
D
_
NO
Button
TIMES VALUES
I
Motor working time
21
0 99
Motor torque
14
8 19
Motor power during
19
Deceleration
10 19
I
Motor
6
Deceleration time
0 (N1 - 2")
P
Delay time before
3
automatic closing
0 99
Pedestrian
7
opening time
0 99 (N1 - 1)
Magnetic limitswitch NO
Proteco S.r.l. Via Neive, 77
12050 Castagnito (CN) ITALY
www.proteco.net - info@proteco.net
PARAMETERS
U S
parameter, the press and hold
DISPLAY SIGNALS
Opening
Closing
Delay time before
automatic Closing
standard
default
FUNCTIONS
values
U S
Press & hold button
C to SAVE changes
B
Press button D
to ABANDON changes
P
SOFT START YES
8 P
Photocells test YES
7 P
YES
Motor test
6 P
Deceleration on YES
4 P
Pre blinking NO
P
Automatic closing YES
step by step
2 P
Multi occupation NO
