Read through ALL instructions before commencing installation.
STOP
If you have any questions about this product or issues with installation, contact
the customer services help line before returning this product to the store.
0333 320 0463
CUSTOMER SERVICES HELP LINE NUMBER:
AVF Group Ltd. Hortonwood 30, Telford, Shropshire, TF1 7YE, England
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AVF JAK101
Summary of Contents for AVF JAK101
- Page 1 If you have any questions about this product or issues with installation, contact the customer services help line before returning this product to the store. 0333 320 0463 CUSTOMER SERVICES HELP LINE NUMBER: AVF Group Ltd. Hortonwood 30, Telford, Shropshire, TF1 7YE, England...
-
Page 2: Tools Recommended
It is the responsibility of the installer to ensure that the mounting wall is of a suitable standard and void of any services (eg gas, electricity, water etc). AVF accept no responsibility for any damage or loss caused by installing this product in a sub standard wall. - Page 3 TV Screws, Reducers and Spacers...
- Page 4 Measure the TV fixing holes Width and Height TV Fixing Holes X 50 - 800mm Y 50 - 400mm If width X is greater than mm or height Y greater than STOP installation now and contact the customer help line You are provided with diameters of TV M4 =...
- Page 5 Mounting Above Please select your method of attaching your Soundbar to your TV and follow the appropriate steps. Free Standing TV - Steps Free Standing TV with SONOS playbar adaptor - Steps 2 + 3 + 4 TV Bracket / TV Furniture - Steps 3 + 4 TV Bracket / TV Furniture with SONOS playbar adaptor - Steps 2 + 3 + 4...
- Page 6 Mounting Above Fitting the TV Brackets No Spacers Spacers For TVs with flat / unobstructed back For TVs with irregular / obstructed back WARNING After completing step you will have fittings left over, please keep for future reference...
- Page 7 Screw diameter dependant If required Example shown is 400 x 400 fixings and / or and / or and / or and / or Attach the bracket to the back of your TV using suitable screw, reducer and spacer combinations...
- Page 8 Mounting Above Attaching TV Mount If you are attaching your Soundbar to a wall mounted TV please use this step in conjunction with the instructions provided with your TV wall mount. MUST be M6 fixings The brackets and screws etc shown in grey are only an example. These are supplied by the TV wall mount manufacturer.
- Page 9 Mounting Above Attaching Soundbar Adjust part to the depth of your Soundbar 47mm 175mm Attach part and then remove backing paper...
- Page 10 Mounting Above Attaching SONOS playbar adaptor Attaching SONOS playbar Mounting Above Whenever possible always use locking screw...
- Page 11 Mounting Below Please select your method of attaching your Soundbar to your TV and follow the appropriate steps. Free Standing TV - Steps Free Standing TV with SONOS playbar adaptor - Steps 2 + 3 + 4 TV Bracket / TV Furniture - Steps 3 + 4 TV Bracket / TV Furniture with SONOS playbar adaptor - Steps 2 + 3 + 4...
- Page 12 Mounting Below Fitting the TV Brackets No Spacers Spacers For TVs with flat / unobstructed back For TVs with irregular / obstructed back WARNING After completing step you will have fittings left over, please keep for future reference...
- Page 13 Screw diameter dependant If required Example shown is 400 x 400 fixings and / or and / or and / or and / or Attach the bracket to the back of your TV using suitable screw, reducer and spacer combinations...
- Page 14 Mounting Below Attaching TV Mount If you are attaching your Soundbar to a wall mounted TV please use this step in conjunction with the instructions provided with your TV wall mount. MUST be M6 fixings The brackets and screws etc shown in grey are only an example. These are supplied by the TV wall mount manufacturer.
- Page 15 Mounting Below Attaching Soundbar Adjust part to the depth of your Soundbar 47mm 175mm Attach part and then remove backing paper...
- Page 16 Mounting Below Attaching SONOS playbar adaptor Attaching SONOS playbar Mounting Below Whenever possible always use locking screw...
- Page 22 Attaching Soundbar Mounting Above or Below Adjust part to the depth of your Soundbar Attach part and then remove backing paper 47mm 175mm Attaching SONOS playbar Mounting Above or Below...
