CPZL8555-C
To register your product/ warranty visit:
Pour enregistrer votre produit/garantie, visitez le:
register.avfgroup.com
Read through ALL instructions before commencing installation.
If you have any questions about this product or issues with installation
contact the customer services help line before returning this product to
the store.
Lisez toutes les instructions avant de débuter l'installation.
Si vous avez des questions sur ce produit ou des problèmes
ATTENTION
d'installation, contactez l'assistance client avant de ramener le produit
en magasin.
This bracket is intended for use with 80" Maximum televisions weighing
!
Maximum 68kg (150lbs). Use with products heavier than maximum weights
may result in instability causing possible injury.
Cette applique doit être utilisée pour des téléviseurs de 80" maximum et
!
pesant au maximum 68kg
poids maximum peut causer de l'instabilité provoquant de possibles accidents.
CUSTOMER SERVICES HELP LINE NUMBER:
NUMÉRO DE L'ASSISTANCE CLIENT:
1-800 667 0808 (USA)
AVF Incorporated. 3187, Cornerstone Drive, Mira Loma, CA 91752, USA
(150lbs)
. L'utiliser avec des produits excédant le
68kg
150lbs
English language / Langue française
Leaflet No. / Notice n° 463231 rev 02
80"
203cm
