467730
rev00
Read through ALL instructions before commencing installation.
STOP
If you have any questions about this product or issues with installation contact
the customer services help line before returning this product to the store.
CUSTOMER SERVICES HELP LINE NUMBER:
+44 (0) 333 320 0463 (UK)
50kg
1-800 667 0808 (USA)
110lbs
AVF Group Ltd. Hortonwood 30, Telford, Shropshire, TF1 7YE, England
AVF Group, Inc. 2775 Broadway, Cheektowaga, Buffalo, New York, 14227 USA
www.avfgroup.com
Advertisement
Related Manuals for AVF 467730
Summary of Contents for AVF 467730
- Page 1 CUSTOMER SERVICES HELP LINE NUMBER: +44 (0) 333 320 0463 (UK) 50kg 1-800 667 0808 (USA) 110lbs AVF Group Ltd. Hortonwood 30, Telford, Shropshire, TF1 7YE, England AVF Group, Inc. 2775 Broadway, Cheektowaga, Buffalo, New York, 14227 USA www.avfgroup.com...
- Page 2 Assembly Overview 2 Person Installation Recommended Determine TV and Cornermount position Fit Support Arm Assembly Connect TV Tools Recommended Ø12mm (15/32") Masonry 8mm & 13mm Ø5mm (3/16") Wood Stud Finder...
- Page 3 It is the responsibility of the installer to ensure that the mounting wall is of a suitable standard and void of any services (eg gas, electricity, water etc). AVF accept no responsibility for any damage or loss caused by installing this product in a sub standard wall.
- Page 4 Boxed Parts Templates...
- Page 5 TV Screws, Reducers and Spacers...
- Page 6 Measure the TV fixing holes Width and Height 50 - 600mm If width X is greater than mm or height Y greater than mm STOP installation now and contact the customer help line TV Fixing Holes 50 - 400mm M4 = You are provided with 4 diameters of TV fixing screws, M4, M5, M6 and M8.
- Page 7 Attach the bracket to the back of your TV using suitable screw, reducer and spacer combinations.
- Page 8 Determine TV and Cornermount Position Use templates to help you position your TV and Cornermount accurately. Put your TV onto template and draw around it, then cut it to shape Ensure back of TV is level with line Ensure your TV is central Put template on top of Max Open...
- Page 9 Position on top of Ensure hole is inside slot Extend until they make contact with the wall. Please note: You can only attach your Cornermount to Solid Wall or Wood Stud Wall. If you are attaching to Wood Stud Wall the location of the wood studs will determine where you can position If you have at max extension it is possible you will see some of the Support...
- Page 10 You can turn 180° and flip over so that your TV can move further in another direction. The example shows how you can get extra movement to the left by swapping has only a can now small amount of move further adjustment to to the left the left...
- Page 11 Determine TV and Cornermount Height Decide how high you want the bottom of your Measure from the bottom of TV to be from the floor (dimension a ). bracket B to the bottom of your TV (dimension b ) If you have purchased, or plan to purchase, an additional shelf module you will need to take this into consideration as this will affect how high the bottom of your TV can be from the floor.
-
Page 12: Solid Wall
Fitting the Support Arm Assembly Fitting the support arm assembly takes 8 steps. Follow the 8 steps to ensure your support arm assembly is square and level. Position the top hole of bracket over drill point you made in step 4, and mark the bottom drill point Solid Wall Wood Stud... - Page 13 Solid Wall Wood Stud DO NOT over tighten screws. Lubricate screw thread with soap Tighten screws by hand only...
- Page 14 Ensure part is level and align the top hole of bracket with the vertical pencil line e you made in step 4 Mark this as drill point f...
- Page 15 Position the top hole of bracket over drill point f you made in step iii, and mark the bottom drill point Solid Wall Wood Stud 50 x 100mm 12.5mm (2 x 4") Min 100mm (4") Min (½") Max Concrete Take care Take care Ø12mm Ø5mm...
- Page 16 Solid Wall Wood Stud DO NOT over tighten screws. Lubricate screw thread with soap Tighten screws by hand only Remember to assemble parts the correct orientation.
- Page 17 viii...
- Page 18 Fitting the TV Bracket Check bracket A is level before fully tightening...
- Page 19 Connecting the TV Optional Lock Tilt Turn Slide Check all fittings are tight...
- Page 20 Optional Shelves You can purchase a separate shelf module which can be built as either 1 or 2 shelves. There will be detailed installation instructions packaged with the shelf module.
