Read through ALL instructions before commencing installation.
STOP
If you have any questions about this product or issues with installation, contact
the customer services helpline before returning this product to the store.
Advertisement
Related Manuals for AVF 469104
Summary of Contents for AVF 469104
- Page 1 469104 www.avfgroup.com rev02 35kg 77lbs Read through ALL instructions before commencing installation. STOP If you have any questions about this product or issues with installation, contact the customer services helpline before returning this product to the store.
-
Page 2: Assembly Overview
Assembly Overview Tools Recommended Fit the TV Mounting Plate Stud Finder Fit the Wall Bracket Ø10mm (25/64”) Ø3mm (1/8”) Hang the TV Masonry Wood Suitable Wall Types Solid Wall Wood Stud... - Page 3 It is the responsibility of the installer to ensure that the mounting wall is of a suitable standard and void of any services (eg gas, electricity, water etc). AVF accept no responsibility for any damage or loss caused by installing this product in a substandard wall.
- Page 4 Boxed Parts TV Screws, Reducers and Spacers...
- Page 5 Measure the TV fixing holes Width and Height 75 - 400mm TV Fixing Holes 75 - 400mm If width X is greater than mm or height Y greater than STOP installation now and contact the customer help line. M4 = M6 = M8 = M4, M6 and M8.
- Page 6 Preparing the TV Mounting Plate Use the option that fits your TV OPTION 1 OPTION 2 X 75mm x Y 75mm X 75mm - 400mm Y 75mm - 400mm X 100mm x Y 100mm X 100mm x Y 200mm X 200mm x Y 100mm SLOTS X 200mm x...
- Page 7 OPTION 2 Adaptors C can be fixed in different positions in the slots on Plate B to match your TV fixing holes. 400mm 300mm 400mm 300mm 200mm 400mm 400mm 200mm Example shown is 400 x 400 fixings...
- Page 8 Fitting the TV Mounting Plate No Spacers Spacers For TVs with flat / unobstructed back. For TVs with irregular / obstructed back. WARNING After completing step you will have fittings left over, please keep for future reference.
- Page 9 Attach the bracket to the back of your TV using suitable screw, reducer and spacer combinations. If required...
- Page 12 Fitting the Wall Bracket Covers Hanging the TV Hanging the TV...
- Page 13 Locking the TV Fitting the Cable Management...
-
Page 14: Tilt Adjustment
Tilt Adjustment Adjust screws to achieve perfect tilt resistance if required. DO NOT overtighten TV Levelling...
