466526
###
jl.avfgroup.com
rev00
JNL204
20kg
44lbs
Read through ALL instructions before commencing installation.
STOP
If you have any questions about this product or issues with installation, contact
the customer services help line before returning this product to the store.
0333 320 0463
CUSTOMER SERVICES HELP LINE NUMBER:
AVF Group Ltd. Hortonwood 30, Telford, Shropshire, TF1 7YE, England
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AVF JNL204
Summary of Contents for AVF JNL204
- Page 1 If you have any questions about this product or issues with installation, contact the customer services help line before returning this product to the store. 0333 320 0463 CUSTOMER SERVICES HELP LINE NUMBER: AVF Group Ltd. Hortonwood 30, Telford, Shropshire, TF1 7YE, England...
- Page 2 Assembly Overview Tools Recommended Fit the TV Mounting Plate Stud Finder Fit the Wall Bracket Ø10mm (25/64”) Ø3mm (1/8”) Masonry Wood Connect the TV Suitable Wall Types Solid Wall Wood Stud...
-
Page 3: Table Of Contents
It is the responsibility of the installer to ensure that the mounting wall is of a suitable standard and void of any services (eg gas, electricity, water etc). AVF accept no responsibility for any damage or loss caused by installing this product in a sub standard wall. - Page 4 Boxed Parts...
-
Page 5: Measure The Tv Fixing Holes Width And Height
TV Screws, Reducers and Spacers Measure the TV fixing holes Width and Height TV Fixing Holes X 50 - 200mm Y 50 - 200mm If width X is greater than mm or height Y greater than STOP installation now and contact the customer help line You are provided with diameters of TV M4 =... -
Page 6: Removing The Tv Mounting Plate
Removing the TV Mounting Plate Remove and safely keep for step 8. Preparing the TV Mounting Plate Use the option that fits your TV OPTION 1 OPTION 2 OPTION 3 X 50mm x Y 50mm X 100mm x Y 200mm X 200mm x Y 200mm X 75mm x... - Page 7 OPTION 2 OPTION 3 200mm 100mm 200mm 200mm 200mm 100mm Example shown is 200 x 200 fixings...
-
Page 8: Fitting The Tv Mounting Plate
Fitting the TV Mounting Plate No Spacers Spacers For TVs with flat / unobstructed back For TVs with irregular / obstructed back WARNING After completing step you will have fittings left over, please keep for future reference... - Page 9 Screw diameter dependant If required Fixings shown are valid for options s 1, 2 & 3. and / or and / or and / or and / or Attach the bracket to the back of your TV using suitable screw, reducer and spacer combinations...
-
Page 12: Assemble The Bracket
Assemble the Bracket Firmly push part with an even steady force (do not use a hammer) until part F, G and H has slid into position and enough thread is showing to attach parts... -
Page 13: Fitting The Wall Covers
Fitting the Wall Covers Carefully bend apart the 2 highlighted sections shown above and then slide into position Click! Click! -
Page 14: Connecting The Tv
Connecting the TV Attach TV TV Locking... -
Page 15: Cable Management
Cable Management Ensure cables don’t restrict arm movement Check all fittings are tight... - Page 16 Optional DO NOT overtighten Lock tilt TV Levelling Storing the Allen Key...
