Figure 3-11. Connecting the MPLAB
Nano
NC
ID
CDC RX
CDC TX
DBG1
DBG2
The MPLAB PICkit 4 In-circuit Debugger/Programmer is capable of delivering high voltage on the MCLR
CAUTION
pin. R110 can be permanently damaged by the high voltage. If R110 is broken, the on-board debugger can
not enter Programming mode of the PIC16F15244, and will typically fail at reading the device ID.
To avoid contention between the external debugger and the on-board debugger, do not start any
CAUTION
programming/debug operation with the on-board debugger through MPLAB
programming while the external tool is active.
©
2020 Microchip Technology Inc.
PIC16F15244 Curiosity Nano
™
®
PICkit
4 In-Circuit Debugger/Programmer to PIC16F15244 Curiosity
MPLAB® PICkit™ 4
8
7
6
5
4
3
2
1
CLOCK
USB
PS LED
DEBUGGER
CURIOSITY NANO
User Guide
Curiosity Nano
1 = MCLR
2 = VDD
3 = Ground
4 = PGD
5 = PGC
6 = Unused
7 = Unused
8 = Unused
MCLR
V
DD
Ground
DATA
VBUS
VOFF
DBG3
DBG0
GND
VTG
®
X IDE or mass storage
DS50003045A-page 23
