Summary of Contents for Wali WL-TTM-1
- Page 2 Supplied Par ts List (1)Wall Plate (2)Monitor Bracket (1)Bubble Level-a (1)Allen Key-b (4)M4 Spacer-c (8)M6/M8 Spacer-d (4)M4 Washer-e (4)M6 Washer-f (4)M8 Washer-g (4)M4x12 Bolt-h (4)M4x30 Bolt-i (4)M6x20 Bolt-j (4)M6x35 Bolt-k (4)M8x20 Bolt-l (4)M8x35 Bolt-m (4)M8x50 Bolt-n (4)Bolt Cover-o (4)Lag Bolt Washer-p (4)Lag Bolt-q (4)Concrete Anchor-r 4mm Drill Bit...
- Page 3 Mounting the Wall Plate to the Wall Step 1 Wood Studs Wall 65mm Brick or Concrete Wall 65mm 60mm 10mm CAUTION! This TV mount must be securely attached to the vertical wall. If the mount is not properly installed it may fall, resulting in possible injury WARNING and/or damage.
- Page 4 Mounting the Monitor Brackets to a TV Step 2 First of all, make sure the diameter of the Bolt(h to n) your TV requires. Once you have determined the correct diameter, please see the diagram as below. You will thread the Bolt into the TV using the correct Washer(e,f,g), and using the spacer(c,d) if necessary.
- Page 5 Adjust the Tilting Angles Step 4 First loosen the bolts, then pull the TV to the desired angle, finally fasten the bolts. Using the provided Allen Key(b). Remove the TV from the TV Mount Step 5 To take off the TV from the TV mount, you need to adjust the tilting angle to 0 degree firstly.
