Summary of Contents for CAME BRIDGE PSAP01
- Page 1 TRIPOD 119G3784EN TURNSTILES INSTALLATION MANUAL BRIDGE PSAP01 - PSAP07N - PSAP08 English...
- Page 2 • This product should only be used for the purpose for which it was explicitly accessible connections. Keep any joints lubricated and clean, and do the same designed. Any other use is considered dangerous. CAME Cancelli Automatici where friction may occur • Perform functional tests on photocells every six S.p.A.
- Page 3 UNLESS EXPRESSELY STATED THE OPERATIONS SHALL BE VALID FOR ALL MODELS OF THE BRIDGEES REGARDLESS OF THE DRAWINGS SHOWN IN THIS MANUAL. REGULATORY REFERENCES This product has been designed and built by CAME CANCELLI AUTOMATICI S.p.A. in compliance with applicable safety standards in the declaration of conformity. DESCRIPTION 001PSAP01 One-way mechanical turnstile in galvanised painted steel (RAL 7035), complete with hydraulic damper.
- Page 4 Description of the components PSAP01 PSAP01 PSAP07N PSAP07N Legs Cover lock Legs TOR100A control panel Cover lock Tripod Screws and washers for fixing Tripod Screws and washers for fixing Sheet metal casing the legs to the casing Sheet metal casing the legs to the casing Housing Housing...
-
Page 5: General Instructions For Installation
Examples of use ⚠ The output managed by a turnstile should not be considered an emergency exit! Always provide an exit for emergency situations and for the physically impaired. Standard installation Wall flanking installation Multiple installation (mm) Recommended distance. GENERAL INSTRUCTIONS FOR INSTALLATION ⚠... - Page 6 Preparing the turnstile Open the lock using the key , lift the cover and slightly pull it forward while pulling it upwards . Lift the casings and remove them PSAP08 PSAP08 PSAP01 PSAP01 ☞ The turnstile comes with an anti-clockwise rotation mechanism installed in the factory;...
-
Page 7: Electrical Connections
Securing the turnstile The floor on which is fixed the turnstile must be The location in which to fix the turnstile depends Drill the marked holes and insert the dowels into perfectly level. on the size of the gap and the possible accessories them. - Page 8 Description of the components TOR100A 1. Transformer 2. Transformer terminal block 3. Accessory fuse 4. Entrance/exit sensor terminal block 5. Line fuse 6. Power supply terminal block 7. Terminal block for control and safety devices 8. Electric lock terminal block 9.
- Page 9 Transformer White Red (230 V AC) White Black (120 V AC) Blue Blue Electric lock PSAP08 PSAP08 Devices to be connected Direction arrows PSAP07N PSAP07N PSAP08 PSAP08 Control devices Terminal block for 24 V AC powering of accessories with maxi- mum current and power draw of 500 mA and 35 W respectively.
-
Page 10: Final Operations
FINAL OPERATIONS ⚠ Make sure that the hydraulic damper is correctly adjusted (see specific chapter). Mount the side casings . Lower the lid and pull it back slightly . Close the lock using the key PSAP08 PSAP08 ADJUSTING THE HYDRAULIC DAMPER... -
Page 11: Maintenance
MAINTENANCE Before any maintenance, disconnect line voltage to prevent any possible dangerous situations that can be caused by accidental movement. For proper maintenance of steel, please consult the manual 119RW48 on steel cleaning operations. Periodic maintenance Model Operating Limits MCBF PSAP01 Maximum number of daily cycles: 15,000 PSAP07N... -
Page 12: Dismantling And Disposal
☞ CAME CANCELLI AUTOMATICI S.p.A. implements an EN ISO 14001-certified and compliant Environmental Management System at its plants, to ensure environmental protection. Please continue our efforts to protect the environment, something that CAME considers to be one of the foundations in developing its business and market strategies, simply by observing brief recommendations as regards disposal: DISPOSAL OF PACKAGING Packaging components (cardboard, plastic, etc.) can be disposed of together with normal household waste without any difficulty, by simply separating the different types of...
