- Page 1 TRIPOD TURNSTILE INSTALLATION MANUAL PSAP01A - PSAP01O - PSAP07 English...
-
Page 2: Read Carefully
Warning Sings (e.g. gate plate). (i.e. that for which it was expressly built for). Any other use is Special instructions and to be considered dangerous. Came Cancelli Automatici S.p.A. advice for users is not liable for any damage resulting from improper, wrongful •... -
Page 3: General Conditions Of Sale
3. ORDERS The sale agreement is executed once the written order is confirmed by Came Cancelli Automatici Spa or when the order is fulfilled by the company. Orders that are addressed, and signed by clients, to Came Cancelli Automatici SpA are deemed to be firm and irrevocable for 30 days starting from the date they are received by the company. -
Page 4: Legend Of Symbols
4 Description 4.1 Turnstile This product is designed and built by CAME Cancelli Automatici S.p.A. in compliance with the current safety legislation. Guaranteed 24 months unless tampered with. Selective, bidirectional, electromechanical turnstile, entirely made of AISI 304 stainless steel with “scotch-brite” fi nish, fi tted with a removable top cover with key lock, and removable side legs. -
Page 5: Application Examples
5 Application examples Warning: an exit fitted with a turnstile cannot be an emergency exit. There must always also be an emergency exit for physically impaired persons. Standard installation Against the wall installation Multiple installation Platform installation 6 Installation Only skilled, qualified staff must perform the installation, in full compliance of the current legislation. Before installing the automated device, please: •... - Page 6 6.2 Positioning the turnstile Depending on the measurements of the Depending on the measurements of the transit opening, choose where to position the turnstile and any accessories. Set up electrical cable conduits next to the turnstile. If the floor cannot be dug, then use the (TRPE) platform to secure the turnstile and any accessories. 6.3 Disassembling and securing the turnstile to the ground Warning: installation required two people.
- Page 7 Position the turnstile in the exact point where it will be anchored and mark the holes with a pencil. Ø20 mm Ø40 mm Remove the turnstile and apply (Ø 12mm) holes where you have marked them. Insert the Ø 12mm, minimum length 50 mm gussets into the holes you have made.
-
Page 8: Control Panel
7 Electric cabling Once the turnstile is secured to the ground, car- ry out the following cable connections. Run through the conduits as shown in the figure and carry out the shown connections. The cables inserted into the electrical panel box must be secured using the apposite cable gland. -
Page 9: Main Components
8.2 Main Components Transformer Transformer connection terminals 1.6A accessories Fuse Endpoint connection terminal 1.6A line fuse 230V A.C. control board power terminals Terminals for connecting accessories and command and control systems. Electro-block connection terminal board Stop/Go lights connection terminal board (optional) EbA EbA EbI 9 Electrical connections 9.1 Power... - Page 10 EbA EbA EbI EbI Electroblocks 9.3 Connecting optional devices to the control panel Terminals to power accessories: 24V A.C. / 500 mA Stop Button / (N.C. Contact) Activating the contact causes the turnstile to completely block. Clockwise activating button / (N.O. contact) If after 10”...
-
Page 11: Safety Instruction
9.4 Connecting optional anti-intrusion devices to the control panel Anti-intrusion photocell (N.C. contact) Photocell Anti-intrusion sensors placed in line with the passage way, activate a Buzzer, in case of any Photocell climb-over attempts. 10 11 1 2 3 4 EM 2 S1 S2 Anti-intrusion Pressure sensor / (N.C. -
Page 12: Maintenance
12 De-commissioning and disposal Came Cancelli Automatici company is ISO 9001:2000 certified for its in-house quality system and ISO 14001 certified in terms of its environmental practices.We kindly ask you to keep on respecting the environment – CAME considers this one of the fundamentals... - Page 13 (+39) 0422 4940 - fax (+39) 0422 4941 it is entirely complete and/or incorporated in compliance with what is set internet: www.came.it - e-mail: info@came.it forth by Machine Directive 98/37/CE Hereby states under its own liability, that these products to automate gates, and garage...
- Page 14 (+33) 4 91 60 69 05 (+49) 71 5037830 (+49) 71 50378383 CAME Automatismos S.a. CAME Automatismos S.a. CAME Americas Automation Llc CAME Americas Automation Llc C/juan De Mariana, N. 17-local 1560 Sawgrass Corporate Pkwy, 4th Floor 28045 Madrid -...
