Breas Vivo30 User Quick Reference Manual

Product Description
1
2
3
4
5
N . I N . I
O TEM O TEM
1 Air inlet 6 AC inlet
2 Rear lid lock 7 On/Off
3 Air outlet 8 External DC inlet
4 Memory card slot 9 Data connection
5 HA 20 humidifier 10 Internal battery or
base
Symbols Used in the Menu
S D
YMBOL ESCRIPTION
Battery level
Alarm time active
HA 20 humidifier active
Ramp active
Panel locked (home mode) On, Off
Panel locked (home mode)
by the Breas Vivo PC
software
Checking the Vivo Before Use
1. Connect a cleaned or new patient circuit to the Vivo.
2. Connect the Vivo to the mains supply.
3. Switch on the Vivo main power using the On/Off button
on the side panel.
4. Check patient settings.
5. Press the Start/Stop button on the front panel.
6. Put on the mask and adjust it's fit.
7. Ensure that the settings are adjusted as prescribed.
The Vivo is ready for use.
6
Viewing the Settings and Alarm History
7
To show settings:
8
Enter the main screen and press up
9
button for 5 seconds.
10
To show alarm history and alarm
settings:
Enter main screen and press down
button for 5 seconds.
U
NIT
Hour : Minute
1 to 9, Off
Minute
On, Off
Breas Medical AB, Företagsvägen
SE- 435 33 Mölnlycke, Sweden,
Phone: +
46 31 86 88 00
breas@breas.com
Find your local distributor at
,
1
, Fax: + ,
46 31 86 88 10
ENGLISH
www.breas.com
Vivo30/40
User Quick Reference Guide
Doc. 004448 En-Uk A-1
