Kohler HD Series Service Manual page 62

Reassembly
Install Governor Assembly
1. Install governor lever onto governor shaft with lever
up.
2. Attach throttle linkage and linkage spring to top of
governor lever.
Control Components
A
F
Flywheel Brake
A
Spring
C Linkage Spring
E Governor Spring
G Screw
Install Speed Control Bracket
NOTE: There are 3 diff erent speed bracket variations for
this engine. Images shown identify how diff erent
brackets connect to carburetors with and without
choke.
Loosely attach speed control bracket to crankcase. On
engines equipped with a fuel pump, fuel pump bracket
secures on same stud as one leg of speed control
assembly.
62
B
C
D
E
H
G
Fixed Speed Control
B
Bracket
D Governor Lever
F Throttle Linkage
H Nut
KohlerEngines.com
Speed Bracket Details
D
E
F
E
E
D
Fixed Speed with
A
Auto Choke
Variable Speed with
C
Auto Choke
E Throttle Lever
G Linkage Spring
I Governor Spring
High Speed
K
Adjustment Tab
High Speed
M
Adjusting Screw
Install Governor Spring
Install governor spring between governor lever and
speed control bracket.
G
H
K
J
I
A
H
F
G
D
M
I
B
H
G
F
M
I
C
Variable Speed with
B
Standard Choke
D Choke Linkage
F Throttle Linkage
H Governor Lever
Fixed Speed Control
J
Bracket
Variable Speed
L
Control Bracket
14 690 10 Rev. --
L
L
