VECTRIX VX-2 SERVICE MANUAL
SECTION E-3: CHECK OF CHARGER FUNCTION
1. Normal function
If the Charger is connected and the indication led on the charger is at 60%, turn on the scooter and
the battery voltage indication of the speedometer should show 59.5 V + 1.0 V.
During the charging process at 60%, the current should be 10.0 A + 0.8 A, measured with a clamp
ampere meter on the brown wire close to the charger DC-plug.
If not, check the voltage with a digital voltmeter on the Controller power in line (red and black thick
wire). The value should be 59.5 V + 1.0 V. If yes, exchange speedometer, if not, exchange Charger.
2. Charger didn't start
Using a Digital Multi meter:
- Open the cover seat
- Measure on the charger connector of the scooter if the voltage is like the battery voltage indication
of the speedometer. If the voltage is zero, check the fuse #2 (30A) of the converter or the
connection cable. If the voltage is lower than 33 V check the voltage of each battery and
exchange the battery which is lower than 10.0V.
- Exchange Charger
