WElcoME!
Thank you and congraTulaTions
for purchasing the Vectrix Maxi Scooter! You are helping the environment and your daily commute as well! We hope that you enjoy the experience! If you need any
repairs to your Vectrix or just want some friendly advice, please see your local dealer service center. This manual is provided to help you get to know your Vectrix.
Enjoy your Vectrix
Maxi scooter
VECTRIX ZEV OWNER'S MANUAL
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vectrix ZEV
Summary of Contents for Vectrix ZEV
- Page 1 Vectrix Maxi Scooter! You are helping the environment and your daily commute as well! We hope that you enjoy the experience! If you need any repairs to your Vectrix or just want some friendly advice, please see your local dealer service center. This manual is provided to help you get to know your Vectrix.
-
Page 2: Table Of Contents
Performance Data Rear Shock Absorbers Rear Wheel Drive USa infOrMaTiOn Battery Pack Safety Defects Motor Controller Label Locations SWiTZerlanD infOrMaTiOn Pre-Ride Checks Power cut off information Interlocks Braking Parking the Vehicle Charging the Battery rOUTine MainTenanCe reCOrD VECTRIX ZEV OWNER’S MANUAL... -
Page 3: General
Your Vectrix is warranted for twenty-four months. Warning! To maintain the warranty you must comply with the servicing requirements called out in the Vectrix When this symbol is shown, it means that you Warranty Book. must read this section. Failure to read this section... -
Page 4: Safe Riding
Sudden braking can passenger grab rail or wrapped around the driver cause the Vectrix to become unstable and cause an of the Vectrix at all times that the Vectrix is in ALWAYS remain seated while riding the Vectrix. accident. -
Page 5: Maximum Weight Allowance
The maximum gross vehicle weight is 938 lbs. (425 kg), which includes the Vectrix, rider, passenger and cargo. Make sure any luggage put on the Vectrix is firmly placed and secured. Do not overload your Vectrix or arrange heavy items higher up on the Vectrix. Do not attach items to the handlebars. -
Page 6: Vehicle Identification Number (Vin)
The VIN is a 17-digit alphanumeric code which uniquely identifies your bike. The VIN meets NHTSA (US) and ISO (EU) requirements. The VIN number should be used when ordering parts so that Vectrix can access its database to ensure that the correct and appropriate parts are provided. -
Page 7: Controls
Warning! In order to properly run your vehicle, you must read and understand this section of the manual. It will help you get more familiar with your Vectrix. instrument Cluster left handlebar regen Throttle ignition Switch VECTRIX ZEV OWNER’S MANUAL... -
Page 8: Instrument Cluster
.0 Telltales fuel level lCD left Status lCD Speedometer / Odometer VECTRIX ZEV OWNER’S MANUAL... -
Page 9: Instrument Cluster
. Trip a-B Or ODOMeTer inDiCaTOr 7. reaDY inDiCaTOr your Vectrix. During charging this will indicate the Indicates mileage reading is currently displayed. This is displayed when the system is ready to be charge mode and the charge termination voltage. - Page 10 Vectrix to an authorized dealer to be and adjusts the LCD backlighting. checked. The Vectrix will not operate when the side is in the down or lowered position. There is an interlock Warning! which prevents the Vectrix from being enabled unless the side stand is in the up position.
- Page 11 The push button is marked with an “M” to signify minutes. a4. hOUr aDjUSTMenT This allows you to change the hour on your clock. The push button in marked with an “H” to signify hours. VECTRIX ZEV OWNER’S MANUAL...
-
Page 12: Key Lock/Ignition
/ igniTion Only one key is needed to start your Vectrix, get into 4. GlOVe BOX To do this push the key down and turn it clockwise the storage area, open your glove compartment and In this position you will be able to pop open the to the trunk position. -
Page 13: Left Handlebar Switches
20 seconds and the bike is moving, the horn will chirp to alert the rider that the directional is still active. noTE! left/right Always use turn signals to make other motorists Direction Switch aware of your intentions. horn Switch VECTRIX ZEV OWNER’S MANUAL... -
Page 14: Right Handlebar Switches/Throttle
On/Off Cut-off reverse Switch The throttle on the right handlebar is a distinctive feature of your Vectrix. The throttle is the user interface which determines forward motion as well as implementing regenerative (regen) braking and the reverse feature. The bi-directional throttle is very simple to use. - Page 15 Your Vectrix has the ability to reverse at very low speeds to assist you with maneuvers such as backing out of parking spots. Reverse is only enabled when the Vectrix is completely stopped. The Vectrix will reverse at a slow speed of 2 mph (3 km/h).
-
Page 16: Main Components 6
Charging Cord Throttle (pg 4) (pg 9) Keylock / ignition Switch headlight (pg ) (pg 34) Glove Box Battery (pg 8*) (pg ) Side Stand (pg 7) rear Wheel Drive (pg 0) Center Stand (OpTiOnal) (pg 7) VECTRIX ZEV OWNER’S MANUAL... -
Page 17: Side And Center Stand
Vectrix forward and make sure the center stand Vectrix. is properly retracted. To put the stand back up, move the Vectrix to a vertical position and lift the side stand bar with your noTE! foot. There is a telltale on the middle of the instrument... -
Page 18: Storage Compartments
UnDer-SeaT helMeT STOraGe/TrUnK To close your glove box, simply shut the compartment. The Vectrix has a hidden storage area for your helmet The door locks itself with a click. located under the passenger seat. Your key controls the lock to the under-seat storage compartment. -
Page 19: Rear Shock Absorbers
Your Vectrix is equipped with dual rear adjustable shock absorbers to enhance your riding experience. You should periodically inspect the exterior of the shocks for signs of fluid leakage. If a leak is indicated, see an authorized dealer at your earliest Shock absorbers convenience. -
Page 20: Rear Wheel Drive
Motor cover removal should only be done by an authorized service agent. Removing the motor cover could lead to entrance of dirt and moisture and/or disrupt the adjustment of the encoder. Motor Side Swing arm VECTRIX ZEV OWNER’S MANUAL... -
Page 21: Battery Pack
The fans run in response to temperature and are active while the Vectrix is running and while charging the battery. You will detect the sound of the fans when they are operating. - Page 22 This means your charger memory and battery level need to be synchronized – see troubleshooting guide. If this ‘drop off’ continues to occur on a regular basis it may indicate a problem with the battery contact an authorized dealer. VECTRIX ZEV OWNER’S MANUAL...
-
Page 23: Motor Controller
MoTor conTrollEr The motor controller is the “brain” of the Vectrix and provides the interface between the battery pack and the motor. The design uses a single circuit board for power system interconnections as well as control components and onboard power supplies. The motor... -
Page 24: Use 4
You should use caution at all times while riding your Vectrix. Warning! This Vectrix is designed for and limited to a top speed of 62 mph (100 km/h). You should avoid braking suddenly. Quick braking can cause you to... -
Page 25: Pre-Ride Checks
Make sure the center stand is in the upright After a few moments all malfunction light telltales position. should go off. If they do not go off, have your Vectrix checked at a dealer. Replace the headlight bulb if it “reaDY” inDiCaTiOn has burned out before riding. -
Page 26: Braking
Braking The Vectrix Zero-Emission Vehicle includes a prOper BraKinG patented regenerative (regen) braking throttle Always ‘cover’ the front brake lever with the index which is easy to use and will improve your riding and middle fingers of your right hand when using experience. - Page 27 Never brake suddenly or in a harsh manner. This could cause the wheels to lock and you could lose control of the Vectrix. Bad weather, including slippery wet road, can cause braking to be less effective. Always use caution in wet conditions. Low tire pressure can reduce braking effectiveness, so checking your tire pressure is very important.
-
Page 28: Parking The Vehicle
Parking ThE VEhiclE Stop the Vectrix and put either the side or center stand down for support Turn the handlebar all the way to the left and lock it there by turning the key to the “lock” position. Park the Vectrix in a area visible to other motorists. -
Page 29: Charging The Battery
“hot,” “neutral,” “ground” and a “pilot” pin. In this case the pilot pin is used by the Though it is not recommended by Vectrix, if you AC power source (charging station) to detect the use an extension cord to charge the bike, make... -
Page 30: Maintenance
Manual as well as in the Warranty Book. Warning! If you are unsure of the problem with your Vectrix, take it to an autorized dealer to get it checked out or call 1-877-VECTRIX (832-8749). VECTRIX ZEV OWNER’S MANUAL... -
Page 31: Battery Pack
3 to 5 hour typical charging time. If you have been running the Vectrix for a long period of time and your battery is very hot, you should wait until it cools down before charging, as the battery will take longer to charge when it is very hot (optimal temperature for charging batteries 25°... -
Page 32: Checking Brake Fluid Levels
Air can enter the reservoir if the fluid level is below MIN. This could cause problems in your Vectrix system. Brake fluid should always be topped off and changed on a routine basis. The brake fluid reservoirs are located on the handlebar assembly. -
Page 33: Checking Brake Pads For Wear
Brake pads have a wear mark. If the grooves in the friction material are visible, the pad is not worn. rear BraKe The rear brake pad material should be at least 1mm thick for effectiveness. noTE! See your autorized dealer for brake replacement. VECTRIX ZEV OWNER’S MANUAL... -
Page 34: Bulb Replacement
BulB rEPlacEMEnT Warning! Do not change bulbs immediately after running your Vectrix. Let the lights cool off. Bulbs become hot when the Vectrix is running and need proper time to cool off. Hot bulbs can cause severe burns if handled. -
Page 35: Beam Setting
Vectrix dealer if resetting is required. away. Draw a horizontal line dictated by the headlight center and a vertical line in line with the Vectrix axis. It is better to perform this test in dim light. Switch on the low beam. The height of the light spot should not exceed 9/10 of the height from ground to headlight center. -
Page 36: Fuses
Do not attempt to change these fuses, or you could cause injury or death to yourself and others. The fuse protection scheme for your Vectrix limits access to the fuses to an authorized dealer. You should not attempt to change any fuse on your Vectrix. -
Page 37: Tires
You should replace tires with the standard size recommended. You should avoid larger tires than the recommended size. Failure to do this could result in injury or death. noTE! Always have the tires balanced after replacing them. VECTRIX ZEV OWNER’S MANUAL... - Page 38 Driving on tires with little or no tread is dangerous and could cause an accident. Checking your tread depth is extremely important. Failure to do so could result in riding on bald tires, which can cause injury or death, especially in wet conditions. VECTRIX ZEV OWNER’S MANUAL...
-
Page 39: Cleaning
As with any vehicle it is important that you wash the detergent with running water. After washing your Vectrix, waxing and polishing are your Vectrix on a regular basis to keep the finish recommended to further protect and beautify the in good condition. Never use harsh detergents or After rinsing, wipe off your Vectrix with a wet paint. -
Page 40: Storing
The Vectrix battery will become damaged if the above precautions are not followed. TranSpOrTinG: If you need to secure your Vectrix onto a pallet or another vehicle for transporting, it is recommended that you make use of the two ‘D’ shaped rings at the... -
Page 41: Transporting
See photo Representative tie down - front and back. D-ring locations as seen from under the bike. Brake Hose Rear non-brake side: Protect the swingarm cutting Rear brake side edges (one side) VECTRIX ZEV OWNER’S MANUAL... -
Page 42: Troubleshooting
All of our bikes are carefully inspected before they are delivered to the customer. Even after the bikes are inspected, some technical problems can occur. The following chart offers a guide for you to identify a problem and, if possible, fix it yourself. If you are unable to solve a problem with your Vectrix, take it to an authorized Vectrix technician at your convenience. - Page 43 Recheck switch, turn off/on Scooter plugged in to AC Unplug scooter and store plug fr riding Throttle not set Call Vectrix authorized dealer for instructions Ready light flashing Side stand switch not engaged Check stands/deploy and retract/check connection Charger not working...
-
Page 44: Technical Data
Integrated rear-wheel mounted planetary gear drive Tire preSSUre Front: 32 psi (2.2 bar) BaTTerY TYpe: Rear: 40 psi (2.8 bar) Nickel Metal Hydride (NiMH) raTeD BaTTerY CapaCiTY: *in operation 30 Ah, 3.7 kW-h raTeD BaTTerY VOlTaGe: 125V VECTRIX ZEV OWNER’S MANUAL... -
Page 45: Range
We suggest that you drive conservatively when you 905 lbs (411 kg) or a total weight increase of first get your Vectrix and get to know your bike and 33%! The more mass you are pushing/lifting the Since there are an unlimited number of potential trip your commute. - Page 46 Speed = reduced range 4. hOW DOeS Tire preSSUre affeCT ranGe? As the Vectrix is ridden, heat is generated in the tires from deformation at the contact patch. Higher inflation pressure reduces this deformation, which results in reduced heating of the tire and reduced energy loss.
-
Page 47: Performance Data
65 miles (105 km) @ 25 mph (40 km/h) fraMe: Lightweight aluminum frame WeiGhT allOWanCeS: Underseat / Trunk Capacity 26 lbs. (12 kg) Glove Box Capacity 4 lbs. (2 kg) Cargo Box and Contents not to exceed 20 lbs (9 kg) VECTRIX ZEV OWNER’S MANUAL... -
Page 48: Usa Information
Also contact Vectrix Corporation immediately. If the NHTSA receives multiple complaints, it could lead to an investigation. The NHTSA may opt to recall vehicles if it perceives a safety threat. -
Page 49: Label Locations
The following pages (50-51) display the locations of safety labels and the labels themselves. VECTRIX ZEV OWNER’S MANUAL... - Page 50 For usa VErsions only Warning Your Vectrix is equipped with a warning light when the side stand is lowered (on). However, it is the rider’s responsibility to ensure that the side stand is stowed completely before starting out. Failure to observe this warning could result in an upset and consequent bodily injury.
-
Page 51: Routine Maintenance Record
MainTEnancE rEcord DaTe Of SerViCe MileaGe SerViCe DeSCripTiOn COMMenTS VECTRIX ZEV OWNER’S MANUAL... - Page 52 VECTRIX ZEV OWNER’S MANUAL...
