3. To determine the current position of the Throttle, squeeze the left side brake lever and using a large
rubber band or similar device secure the lever in the squeezed position, and observe the needle
position.
4. To determine the correct position of the Throttle, squeeze the right side brake lever and observe the
reading.
Note: The neutral position of the throttle is 615-639. The ideal setting for this adjustment is 625.
5. Release the right lever and adjust the screw (2) until the readings are the same.
6. Remove the large rubber band or similar to release the left side brake lever.
7. Slightly tighten the set screw; this will secure the screw from moving.
8. Install the right handlebar end cap.
Magnet Holder
LOOKING INTO THE
THROTTLE WITH THE
HANDLEBAR ENDCAP
REMOVED
Set Screw
Regen Throttle Sensor Replacement
S-XC-S00079
Removal Procedure
1. Remove the upper handlebar cover. Refer to Front Console Cover Replacement B-2.
2. Remove the right handlebar end cap and hand grip. Refer to Handlebar End Cap and Hand Grip
Replacement.
3. Remove the kill switch cover screws.
4. Twist the throttle to gain access to the throttle clamp screw (1) and loosen.
5. Remove the throttle sleeve (2) from the handlebar.
Version 1.0/July 2011
