VECTRIX VX-2 SERVICE MANUAL
SECTION C-4: HANDLEBAR-LEFT SWITCH ASSEMBLY
Preparations:
Remove Front Console Cover (for VIN all LYSE and LYSV40002B1000001 to
LYSV40002B1000034)
Remove Vertical Panel Cover-Lower (for ICM access for VIN all LYSE and LYSV40002B1000001
to LYSV40002B1000034)
Remove all cable strips
Open connector CN1 from the Interface Control Module
(ICM)
Additional information see Section 1 of F-1
Unscrew the PH2 Phillips screw
Unscrew the PH2 Phillips screw
Remove the Left Switch assembly
Test functions of Left Switch assembly
https://www.motorcycle-manual.com/
see Section B-2
see Section B-4
Version 1.0/July 2011
VECTRIX, LLC
