The Carbon Filter
If the appliance is going to be used in recirculation mode then it is necessary to fit carbon filter. This will help absorb
odours caused by cooking.
Carbon filters have a limited life. We advise you to change them when there is a noticable drop in peformance.
The intervals between changing the filter will depend entirely upon the amount of cooking you do, but on
average they will last about 3-6 months.
Before installing or replacing the carbon filters, please remove power to the unit.
1. Open the access flaps on the underside of the ceiling hood.
2. Press the lock on the filter frames and remove all the grease filters for ease of access.
3. Turn the carbon filter on both side of the motor anti-clockwise and remove the filter.
4. Replace the carbon filters by locating on the central spigot and turn clockwise.
5. Replace the mesh filters by locating the rear lugs in first and then pushing into place ensuring the lock is
properly engaged.
6. Close the access flaps on the underside of the ceiling hood
7. Connect the power supply to the wall socket.
NOTE: Carbon filters will reduce the suction power of the appliance, they are designed to remove
smells and cooking odours, they will not remove moisture or condensation from the air.
LAM2950 Uses Carbon Filter HJA2906 (2Pk)
