- Page 1 AC COMMERCIAL & RETAIL ELECTRICALLY HEATED, AMBIENT & LPHW 1000 & 1500 & 2000mm High & Standard Capacity Installation and operating manual...
- Page 2 Index Technical specification & safety details Installation details Servicing Element and motor replacement General user instructions Fault finding Spare parts...
- Page 3 1 Technical specification & safety details Health and Safety Sole liability rests with the installer to ensure that all site safety General procedures are adhered to during installation. All installations must be in accordance with the regulations in force Sole liability rests with the installer to ensure that protective safety in the country of use.
- Page 4 Figure 1 Wiring Diagram - Electric Drawing Number - 900092R1...
- Page 5 Figure 2 Wiring Diagram - Ambient / LPHW Drawing Number - 900220...
- Page 6 Figure 3 Dimensions 1000mm 1062 1095 1138 1500mm 1562 1492 1553 1638 2000mm 2062 1992 2053 2138 Technical specification - Electric (415V 50Hz supply required) Model AC1000SE09 AC1500SE12 AC2000SE18 AC1000HE12 AC1500HE18 AC2000HE24 Weight 39.5kg 49kg 60kg 39.5kg 49kg 60kg Element rating 12kW 18kW 12kW...
-
Page 7: Installation Details
2 Installation details Step 4 It is the sole responsibility of the installer to ensure that the points of attachment to the building are sound. Consultation with the consultant/architect or owner of the building is recommended to ensure that a sound, mechanically stable installation is achieved. - Page 8 Holes are provided in the back box for the feed cable to enter the case. Choose the appropriate hole top rear to suit the installation. Insert correct size flat blade screwdriver from underneath. Fit suitable cable gland for size of cable. Step 8 2.1 Installation details - LPHW Only Access to the heating coil and mains terminal block is via...
- Page 9 3 Servicing Step 4 The product should be serviced annually. Airbloc offer a service facility, call 01384 489700. Servicing shall be undertaken by a competent person. Ensure electrical power is isolated from the product. Step 1 Slacken two bolts on both ends. Undo screws securing the grille.
-
Page 10: Motor Replacement
4 Motor Replacement Step 4 Follow steps 1 - 4 below. Remove the rotors and motor from the assembly and replace as required. Step 1 Refit in reverse of the previous steps and test the performance of the product. Remove 3 screws securing fan bearing plate to access panel. Carefully remove plate with bearing housing from rotor bearing. -
Page 11: Element Replacement
Element replacement For access follow steps 1 - 4 of servicing. Step 1 Carefully remove connections to element, noting wiring configuration. Step 2 Remove two bolts securing elements. Step 3 Lift out element cartridge, replace as required. Refit in reverse of the previous steps and test performance of the product. - Page 12 5.1 General user instructions - Electrically Heated 5.2 General user instructions - Ambient & LPHW Figure 4 Figure 5 To operate the air curtain To operate the air curtain First ensure that the electrical supply to the air curtain heater is First ensure that the electrical supply to the air curtain heater is turned on.
-
Page 13: Fault Finding
6 Fault finding 6.1 If the air curtain does not operate after running through the detail provided in Section 3, then a suitably competent service engineer should be called to identify the nature of the fault. Note The manufacturer operates a service function from the address provided in these instructions. -
Page 14: Spare Parts
7 Spare parts Part Numbers Photograph Description AC1000SE09 AC1500SE12 AC2000SE18 & AC1000HE12 & AC1500HE18 & AC2000HE24 Motor 100535 100535 100535 Contactor 900078 900078 900078 Rotor LH 100539 100540 100541 Rotor RH 100536 100537 100538 Thermal cut out 900001 900001 900001 Element Assembly Rating 12kW... - Page 15 For commercial/retail air curtain enquires please contact Ambi-Rad Limited - Airbloc ™ Fens Pool Avenue Brierley Hill West Midlands DY5 1QA United Kingdom Due to continuous product innovation, Telephone 01384 489700 we reserve the right to change product Facsimile 01384 489707 specification without due notice.
