Goodman 1.5 TON Installation Instructions Manual

CEILING MOUNT AIR HANDLERS
INSTALLATION INSTRUCTIONS
Important Safety Instructions
The following symbols and labels are used throughout this
manual to indicate immediate or potential safety hazards. It is
the owner's and installer's responsibility to read and comply
with all safety information and instructions accompanying these
symbols. Failure to heed safety information increases the risk
of personal injury, property damage, and/or product damage.
HIGH VOLTAGE!
Disconnect ALL power before servicing or
installing this unit. Multiple power sources
may be present. Failure to do so may cause property
damage, personal injury or death.
Goodman will not be responsible for injury or
property damage arising from improper service or
service procedures. If you install or perform service
on this unit, you assume responsibility for any
personal injury or property damage which may result.
Many jurisdictions require a license to install or
service heating and air conditioning equipment.
CARBON MONOXIDE POISONING HAZARD
Special Warning for Installation of Furnace or Air Handling Units in
Enclosed Areas such as Garages, Utility Rooms or Parking Areas
Carbon monoxide producing devices (such as an automobile, space
heater, gas water heater, etc.) should not be operated in enclosed areas
such as unventilated garages, utility rooms or parking areas because of
the danger of carbon monoxide (CO) poisoning resulting from the exhaust
emissions. If a furnace or air handler is installed in an enclosed area such
as a garage, utility room or parking area and a carbon monoxide producing
device is operated therein, there must be adequate, direct outside
ventilation.
This ventilation is necessary to avoid the danger of CO poisoning which
can occur if a carbon monoxide producing device continues to operate in
the enclosed area. Carbon monoxide emissions can be (re)circulated
throughout the structure if the furnace or air handler is operating in any
mode.
CO can cause serious illness including permanent brain damage or death.
®
C US
B10259-216
-
© 2005-2008, 2010 Goodman Manufacturing Company, L.P.
5151 San Felipe, Suite 500, Houston, TX 77056
www.goodmanmfg.com -or- www.amana-hac.com
P/N: IO-282E Date: November 2010
Installation and repair of this unit should be performed
ONLY by individuals meeting the requirements of an
"entry level technician"
the Air Conditioning, Heating, and Refrigeration
Institute (AHRI). Attempting to install or repair this
unit without such background may result in product
damage, personal injury, or death.
WARNING
Do not connect to or use any device that is not design
certified by Goodman for use with this unit. Serious
property damage, personal injury, reduced unit
performance and/OR hazardous conditions may result
from the use of such non-approved devices.
WARNING
To prevent the risk of property damage, personal injury,
or death, do not store combustible materials or use
gasoline or other flammable liquids or vapors in the
vicinity of this appliance.
CAUTION
Have your contractor identify all the various cutoff switches
and devices that service this unit. Know where the switch is
that will cut off energy to the heating system in the event of
overheating.
Shipping Inspection
Upon receiving the product, inspect it for damage from ship-
ment. Shipping damage, and subsequent investigation is the
responsibility of the carrier. Verify the model number, specifi-
cations, electrical characteristics, and accessories are cor-
rect prior to installation. The distributor or manufacturer will not
accept claims from dealers for transportation damage or in-
stallation of incorrectly shipped units.
Codes & Regulations
This product is designed and manufactured to comply with
national codes. Installation in accordance with such codes and/
or prevailing local codes/regulations is the responsibility of the
installer. The manufacturer assumes no responsibility for equip-
ment installed in violation of any codes or regulations.
, at a minimum, as specified by
