AMST**14*U00**
AIR HANDLERS INSTALLATION &
OPERATING INSTRUCTIONS
1 Important Safety Instructions .................................... 2
2 Shipping Inspection ................................................... 3
2.1 Parts ....................................................................... 3
2.2 Handling ................................................................. 3
2.3 Shipping Material Removal..................................... 3
2.3.1 Blower Support Bracket Removal ....................... 3
3 Codes & Regulations ................................................. 3
4 Replacement Parts ..................................................... 4
5 Pre-Installation Considerations ............................... 4
5.1 Preparation ............................................................. 4
5.2 System Matches ..................................................... 4
5.3 Interconnecting Tubing ........................................... 4
5.4 Clearances ............................................................. 4
5.5 Horizontal Applications ........................................... 4
6 Installation Location ................................................... 4
6.1 Upflow Installation .................................................. 5
6.2 Horizontal Left Installation ...................................... 5
6.4 Humid Environment Installations ............................ 6
6.4.1 All Installations - Humid Environments ............... 6
7 Refrigerant Lines ........................................................ 7
7.1 Tubing Size ............................................................. 7
7.2 Tubing Preparation ................................................. 7
7.3 Tubing Connections ................................................ 7
8 Condensate Drain Lines ........................................... 10
9 Ductwork .................................................................... 11
9.1 Return Ductwork .................................................... 11
10 Return Air Filters ..................................................... 11
11 Electric Heat ............................................................. 11
12 Electrical and Control Wiring ................................. 12
12.1 Building Electrical Service Inspection .................. 12
12.2 Wire Sizing .......................................................... 12
12.3 Maximum Overcurrent Protection (MOP) ............ 12
12.4 Electrical Connections - Supply Voltage ............. 13
12.4.1 Air Handler Only (Non-Heat Kit Models) ........... 13
12.4.3 Air Handler With Circuit Breaker Heat Kit ......... 13
12.5 Low Voltage Connections .................................... 13
12.5.1 Thermostats ...................................................... 13
12.6 Speed Tap Adjustment ......................................... 14
12.6.1 Selecting Speed Taps 1-5 ................................. 14
12.6.2 Selecting Speed Taps 6-9 ................................. 14
12.6.3 AMST60DU1400** (ONLY) ............................... 14
13 Achieving 1.4% Low Leakage Rate ....................... 16
14 Start-Up Procedure.................................................. 16
15 Regular Maintenance .............................................. 16
16 Airflow Data ............................................................... 17
17 Air Handler Low Voltage Connections ................... 19
18 Wiring Diagrams ...................................................... 20
19 Start-Up Checklist .................................................... 26
Contents
© 2021 Goodman Manufacturing Company, L.P.
Only personnel that have been trained to install, adjust, service
or repair(hereinafter, "service") the equipment specified in this
manual should service the equipment. The manufacturer will not
be responsible for any injury or property damage arising from im-
proper service or service procedures. If you service this unit, you
assume responsibility for any injury or property damage which
may result. In addition, in jurisdictions that require one or more
licenses to service the equipment specified in this manual, only
licensed personnel should service the equipment.
Improper installation, adjustment, servicing or repair of the equip-
ment specified in this manual, or attempting to install, adjust,
service or repair the equipment specified in this manual without
proper training may result in product damage, property damage,
personal injury or death.
RECOGNIZE THIS SYMBOL
AS A SAFETY PRECAUTION.
NOTE: SPECIFICATIONS AND PERFORMANCE DATA LISTED HEREIN
ARE SUBJECT TO CHANGE WITHOUT NOTICE
19001 Kermier Rd., Waller, TX 77484
P/N: IO-4004 Date: July 2021
