Goodman AEPF Manual

Multi-position, variable-speed air handlers 1 1/2 to 5 tons
Hide thumbs Also See for AEPF:
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

Standard Features
• Suitable for use with R-410A and R-22 refrigerants
• Check flowrater expansion device for cooling and
heat pump applications
• Variable-speed motor
• Provides constant CFM over a wide range of static
pressure conditions independent of duct system;
provides low CFM for efficient fan-only operation
• Up to 14 adjustable airflow settings to optimize the
system's CFM for each individual mode of operation
• Improved humidity control and comfort
• Compatible with heat pumps and variable-capacity
cooling applications
• Multi-position - upflow, downflow or horizontal
• Built-in coil has horizontal, vertical, and downflow drain
pans with secondary drain connections
• Complies with the Factory-sealed Air Handling Credit with
or without field-installed filter kits as listed in the 2001
Florida Building Code, Chapter 13, Section 610.2.A.2.1
• AHRI Certified; ETL Listed
Cabinet Features
• Fully insulated, painted steel cabinet with attractive
Architectural Gray finish
• Built-in filter rack for 1" filter (filter not included)
• Low-voltage cabinet connections; control circuit
arranged to permit staging
• Power supply on top; low-voltage entry on top or side
• Factory-sealed to achieve 2% or less leakage rate with
or without field-installed filter kits at 1.0" water gauge
external duct static pressure
* Complete warranty details available from your local dealer or at www.goodmanmfg.com. To
receive the 10-Year Parts Limited Warranty, online registration must be completed within 60
days of installation. Online registration is not required in California or Québec.
SS-GAEPF
M
Contents
Nomenclature ........................................................................ 2
Product Specifications ........................................................... 3
Dimensions ............................................................................ 4
Wiring Diagram . ..................................................................... 6
Accessories ............................................................................. 7
www.goodmanmfg.com
AEPF
-P
, V
ulti
osition
AriAblE
A
H
ir
AndlErs
1½
5 t
to
ons
-s
PEEd
2/10
Supersedes 6/09

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AEPF and is the answer not in the manual?

Questions and answers

Related Manuals for Goodman AEPF

Summary of Contents for Goodman AEPF

  • Page 1: Table Of Contents

    AEPF ulti osition AriAblE PEEd AndlErs 1½ Standard Features • Suitable for use with R-410A and R-22 refrigerants • Check flowrater expansion device for cooling and heat pump applications • Variable-speed motor • Provides constant CFM over a wide range of static pressure conditions independent of duct system; provides low CFM for efficient fan-only operation • Up to 14 adjustable airflow settings to optimize the system’s CFM for each individual mode of operation • Improved humidity control and comfort • Compatible with heat pumps and variable-capacity cooling applications • Multi-position — upflow, downflow or horizontal • Built-in coil has horizontal, vertical, and downflow drain pans with secondary drain connections • Complies with the Factory-sealed Air Handling Credit with or without field-installed filter kits as listed in the 2001 Florida Building Code, Chapter 13, Section 610.2.A.2.1 • AHRI Certified; ETL Listed Cabinet Features • Fully insulated, painted steel cabinet with attractive...

  • Page 2: Nomenclature

    roduct PEciFicAtions oMEnclAturE 3642 5,6,7,8 11,12 Brand Engineering * Single-piece Major/ Minor Revisions Air Handler * Not used for inventory management Unit Application Refrigerant Charge Ceiling Mount PSC Motor No Digit = R-22 only Downflow PSC Motor 6 = R-410A or R-22 Multi-Position Variable-Speed Motor Multi-Position PSC Motor Electrical...
  • Page 3 PEciFicAtions PEciFicAtions AEPF AEPF AEPF AEPF 183016 303616 313716 426016 Nominal Ratings Cooling (BTU/h) 18,000-30,000 30,000-36-000 30,000-36-000 42,000-60,000 CFM (High/ Low) 1,200/ 600 1,200/ 1,000 1,200/ 1,000 2,000/ 1,200 Blower Diameter 9½” 10⅝” 10⅝” 10⅝” Width 8” 10⅝” 10⅝”...

  • Page 4: Dimensions

    12” 14½” ” 19⅝” ” ” AEPF303616 AEPF313716 53¼” 24” 20” 22” 12” 14½” ” 19⅝” ” ” 53¼” 24” 20” 22” 12” 14½” ” 19⅝” ” ” AEPF426016 AEPF d iPswitcHEs The AEPF air handler blower motor is pre-programmed for operation at four distinct airflow levels when operating in the Cooling, Heat Pump heating, Backup heating (Electric Heating), and Backup + Heat Pump heating modes. Each mode has four levels to deliver different CFM. Simply flip the dipswitch for a different CFM combination. Etting tHE otor www.goodmanmfg.com SS-GMVC95...
  • Page 5 PEciFicAtions AEPF d iPswitcHEs cont Dipswitch Function Instructions Number Electric Heat Mode Select the taps allowed in the tables (Dipswitch 1/2/ 7/8) below. Electric Heat Mode ON = The system operates with single-stage units using a single-stage cooling or heat pump thermostat.

  • Page 6: Wiring Diagram

    PEciFicAtions AEPF w iring iAgrAM Wiring is subject to change. Always ⚠ ⚡ High Voltage: Disconnect all power before servicing or installing this unit. Multiple power refer to the wiring diagram or the arning sources may be present. Failure to do so may cause property damage, personal injury, or death. unit for the most up-to-date wiring. www.goodmanmfg.com SS-GMVC95...

  • Page 7: Accessories

    AlVE its For onditioning only PPlicAtions Kit Number Used with Description XVB18-36C AEPF 18 to 36 20% bleed valve XVB42-60C AEPF 42 to 60 20% bleed valve XV18-36C AEPF 18 to 36 Non-bleed valve XV42-60C AEPF 42 to 60...
  • Page 8 HKR-20C HKR-21C SPW-01 ** Must be installed along with any of the above compatible heat kits. This kit will fit any AEPF air handler as long as a compatible heat kit is installed in the unit. iltErs AEPF Filter #...
